• Model NO.：SJSZ65,132
• Customized：Customized
• Condition：New
• Plastic Sheet Extrusion Line Style：Sjsz65,132
• Plastic Sheet Extrusion Line Output：250kg,H
• Plastic Sheet Extrusion Line Power：37kw
• Plastic Sheet Extrusion Line Length：20m
• Transport Package：Separate Wood Case and Pallet
• Specification：ISO9001-2000
• Trademark：LEADER
• Origin：Qingdao China
• HS Code：8477209000
• Production Capacity：100set,Year

Basic Info.

Model NO. SJSZ65/132 Customized Customized Condition New Plastic Sheet Extrusion Line Style Sjsz65/132 Plastic Sheet Extrusion Line Output 250kg/H Plastic Sheet Extrusion Line Power 37kw Plastic Sheet Extrusion Line Length 20m Transport Package Separate Wood Case and Pallet Specification ISO9001-2000 Trademark LEADER Origin Qingdao China HS Code 8477209000 Production Capacity 100set/Year

Product Description

Wave plate has an excellent corrosion resistance, weather resistance, easy processing, low cost and many other characteristicsm abd is widely used for roof material of workshops, warehouses.

Production line consists of:
Extruder: Single-screw extruder PP / PE / PC, conical twin-screw extruder PVC.
T die head: The hanger-type flow structure, a suitable compression ratio to ensure the stability of material flow evenly.

Calibrating molds: Rational design, the unique design of the cooling flow to ensure the accuracy of products,
Hauling machine: Roller traction, using high quality NBR rubber roller, pneumatic adjustment, and frequency speed adjustment.
Cutting Machine: Knife cutting, fast, good accuracy.

Extrusion Line Type SJSZ-65/132 for PVC Single Layer Corrugated Sheet, Including: 1 Set of Twin Screw Extruder SJSZ-65/132 1 Set of Die Head 1 Set of Guide Roller 1 Set of Accessory Equipments for PVC Corrugated Sheet, Calibrating Unit, Edge Cutting Device, Hauling Machine, Knife Cutting Machine and Stacker. 2.1. Twin Screw Extruder SJSZ-65/132 Item Description Unit SJSZ65/132 1 Output Capacity Kg/h Max.250 2 Number of the Screws   2 3 Diameter of the Screw mm 65/132 4 Rotating Direction of the Screws   Forth & Reverse 5 Rotation Speed of the Screw r/min 1-34.7 6 Available Working Length of the Screws mm 1430 7 Main Motor Power Kw 37 8 Speed Adjusting Mode   frequency conversion adjustable, Invertor from OMRON 9 Gear Reducer   Rigid-gear surface low noise design 10 Heating Capacity of the Screw barrel Kw 24 ( casting-aluminium electric-thermal elements ) 11 Material of the Screws  and the barrel   38CrMoALA 12 Nitriding Depth of the Screws and the barrel mm 0.5~0.7 13 Nitriding Rigidity of the Screws and the Barrel HRC 50~55 14 Cooling Mode of the Screw barrel   by air cooling 15 Temperature Adjustment of the Screws   By Screw-core Temperature Adjusting Device 16 Indicators   Melt pressure & temperature indication by gauge 17 Temperature Controllor   Brand: Omron, Japan 18 Element of Electric System ( contactors, buttons, switches )   Brand:  Schneider 19 Power of the Vacuum Pump Kw 1.5 20 Max. Vacuum Degree MPa -0.093 21 Cooling Water Consumption L/min 1~3 22 Plastic Material Feeding Mode   By Fixed-quantity Screw Feeding Device 23 Rotation Speed of the Feeding Screw R/min 3.5~47 ( frequency conversion ) 24 Height of the Screw Axes mm 1000 25 Figure Dimensions ( L×W×H ) mm 4235×1520×2450 26 Weight Kg 4000 2.2. Die Head,   1 set Item Description Unit 1200mm 1 Die head width mm 1200 2 Adjusted thickness mm 0.75-0.8 2.3. Guide Roller, 1 set Item Description Unit 800mm 1 Quantity of the roller   2 2 Diameter of the roller mm 200 3 Width of the roller mm 1250mm 4 Cooling Method   Internal Cooling 2.4. Accessory equipments for PVC corrugated sheet, calibrating unit, edge cutting device, hauling machine, knife cutting machine and stacker. 1 set 2.4.1 . Calibrating Unit Item Description Unit DX-1000 1 Calibrating mould width mm 800 2 Material of mould   40Cr 3 Length mm 500 4 Clamping method   Pneumatic 5 Water pump power KW 3 2.4.2 Edge Cutting Device 2.4.3 . Hauling-off Machine Item Description Unit 1000mm 1 Diameter of rubber roll mm 220 2 Width of rubber rolls mm 800 3 Clamping method   Pneumatic 4 Driving motor kw AC, 2.2KW, OMRON inverter 5 Hauling speed m/min 0.5-4.5 2.4.4 . Knife C utting M achine Item Description Unit 1000mm 1 Method   Knife Cutting 2 Cutting width mm 800 3 Cutting thickness mm 1.2 4 Driving method   Electric 5 Length counter   Digital 6 Cutting Length mm 2500( Adjustable) 2.4.5 . Stacker Item Description Unit   1 Material of working table   Stainless steel 2 Working length   6000
