PP Plastic Bag Film Extruder Machine with Rotary Die Head Price
WENZHOU E-SHION MACHINERY CO., LTD.- Type：PP Film Blowing Machine
- Raw Material：PE
- Maximum Folding Width of Film：600mm
- Screw Diameter：55mm
- Automation：Non-Automatic
- Computerized：Non-Computerized
Base Info
- Certification：CE
- Screw Material：Double Alloy
- Die Head：Rotary Head
- Heater Material：Cast Aluminum
- Motor：China , Siemens Is Optional
- Inverter：China ,Delta or Panasonic Is Optional
- Electric Parts：Schneider ,Panasonic
- Temperature Control：Omron
- Gear Box /Reducer：Shuguang ,Hangzhou Weili
- Winder：Sing , Double
- Air Ring：Double-Lip Air Ring
- Transport Package：Plastic Film ,Bubble Film
- Specification：600mm
- Trademark：E-SHION
- Origin：China
- HS Code：8477309000
- Production Capacity：100sets,Year
Description
If you need other film bolwing machine. Please click here
Main Technical Variables:
Machines in our workshop :
Main Technical Variables:
Model
SJ-55/FM600
SJ-65/TM800
SJ-75/FM1000
Screw
Diameter 55
Diameter 65
Diameter 75
L/D
28:1
28:1
28:1
Film width
100-600MM
300-800MM
300-1000MM
Film thickness
0.01-0.1
0.01-0.1
0.01-0.1
Capacity
45
60
85
Motor power
18.5kw
22kw
30KW
Traction motor
1.1KW
1.5KW
1.5KW
Roll length
650
850
1050
Size
4800*2500*3800
5000*2800*4000
5500*3000*4000
Weight
4tons
5tons
6tons
Machines in our workshop :
