Cincinnati Cmt58 Twin Conical Screw and Barrel for Recycled PVC

ZHOUSHAN JINTANG OULIN MACHINERY CO., LTD.
  • After-sales Service：If Has Quality Defects, a New One Will Be Made.
  • Warranty：180 Days
  • Standard：DIN, JIS
  • Technics：Cutting, Heat Treatment, Pta Welding, Casting
  • Feature：Long Working Life
  • Material：Alloy Steel

Base Info

  • Model NO.：CMT58
  • Transport Package：Plywood Case
  • Specification：CMT58
  • Trademark：OULIN
  • Origin：China
  • HS Code：84779000
  • Production Capacity：500-700 Sets Per Year

Description

Basic Info.

Model NO. CMT58 Transport Package Plywood Case Specification CMT58 Trademark OULIN Origin China HS Code 84779000 Production Capacity 500-700 Sets Per Year

Product Description

Detail Information For Cincinnati CMT58 Twin Conical Screw and Barrel for Recycled PVC:

Application: for cincinnati extrusion, for recycled PVC, pipe extrusion.

Customer's Requirement: good abrasive resistance.

Screw's quality: bimetallic screw, base material: rolled 38CrMoAlA, 10%-15% tungsten carbide powder will be added at screw's alloy layer.

Barrel's quality: barrel will be made into two parts, a alloy liner will be pushed into the extruder zone to increase the abrasive resistance, the rest part will be the nitrided quality, two parts will be connected by bolts.


Detail Information For All Brand Twin Conical Screw and Barrel:

Application:
For the production of pipes, profiles, sheets, such as SPC floor, PVC wall board, PVC wood plastic, PE wood plastic, high molecular sheet, baking-free brick plate, high calcium plate, high calcium pipes, high calcium profiles, soft PVC sheet, PVC foam board, PP, PE, ABS, PVC, granulation and etc.

Specification:
24/52, 35/76, 45/90, 45/100, 50/105, 51/105, 55/110, 55/120,58/124, 60/125, 65/120, 65/132, 68/143, 70/135,70/140, 75/150, 80/143, 80/156, 92/188, 105/213,110/220 and others.

1: Factory can produce twin conical screw and barrel according to your drawings.
2: Engineer can be sent to your factory for measurement, company can produce screw and barrel for most extrusion brand.

Quality:
1: Nitriding quality------ base material: 38CrMoAlA(JIS SACM645)
2: Bimetallic quality-----Good abrasive& corrosive resistance.

Heat treatment:
Advance hardening and tempering
Nitriding treatment

Technical Parameters:
Nitriding depth: 0.50mm-0.80mm
Nitriding hardness: HRC56-58
Surface roughness: Ra 0.4
Screw straightness: 0.015mm
Alloy layer depth: 2mm-3mm
Alloy layer hardness: HRC56-64

OULIN SCREW:  YOUR LOYAL PARTNER FOR SCREW AND BARREL
