• Machine Weight：8T
• Certification：CE, ISO9001:2008, UL
• Transport Package：Wooden Packing
• Specification：14cbm
• Trademark：BROTHER UNION
• Origin：Ruian
• HS Code：8477301000
• Production Capacity：20sets,Montth

FEATURESUITABLE MATERIALHDPE, LDPE,LLDPELAYER NUMBER1-LayerFILM THICKNESSHD: 0.01-0.06MM, LD: 0.03-0.08MMMAX OUTPUT80KG/HMAX FILM WIDTH1000MMEXTRUSION UNITSCREW DIAMETERΦ55X1SCREW L/D RATIO30/1SCREW MATERIALBIMETALLICBARREL MATERIALBIMETALLICBARREL THERMO CONTROL3X1BARREL COOLING FAN200WX3X1SCREEN CHANGERSTANDARDDRIVING MOTOR22KWX1  SIEMENSGEARBOX#180EXTRUSION DIE UNITDIEHDΦ80/100DIE TYPEFIXEDDIE THEROMO CONTROL2AIR RINGDUAL LIPFLANGE THERMO CONTROL2AIR BLOWER5.5KW, CHUANFAN TAIWANTAKE UP UNITTAKE UP TYPEFIXEDBUBBLE CAGE MATERIALWOODENTOP NIP MATERIALWOODENTAKE UP ROLL MATERIALHIGH TEMP RUBBERTAKE-UP ROLLER LENGTH1000MMGUSSETINCLUDEDTAKE-UP MOTOR1.5KW GEAR MOTORTAKE-UP SPEED10-80M/MINPINCH PATTERNPNEUMATICWINDING UNITWINDING TYPESINGLE MANUAL WINDERWINDING ROLLER LENGTH1000MMWINDING SHAFTSTOPPER SHAFTX2BANANA ROLLERWITHMAX DIA.OF WINDED ROLL800MMWINDING MOTORTORQUE MOTORSPEED CONTROLSPEED CONTROLLERCONTROL PANELHEATING SYSTEMACR+PID (ENERGY SAVING)TEMP. CONTROLLERFOTEK (TAIWAN)WORKING VOLTAGE380V,50HZINVERTER BRANDDELTA


Optional equipment:

1). Auto load
2). Air compressor
3). Special die
4). Die rotary device
5). Bouble sides winder
6). Up and down



Details Information
