Fully-Automatic Bottle Blow Moulding Machine with 2 Cavity

Zhangjiagang Eceng Machinery Co., Ltd.
  • Type：Stretch Blow Molding Machine
  • Raw Material：PET
  • Making Method of Parison：Injection Blowing
  • Automation：Automatic
  • Computerized：Computerized
  • Certification：CE, ISO9001:2008, QS, UL, GMP

Base Info

  • Model NO.：YCQ-2L-2E
  • Bottle Material：Pet
  • Cavity：2
  • Output：1500bph
  • Bottle Volume：150ml-2L
  • Driven Type：Pneumatic
  • Dimension(L*W*H)：3.5*1.6*1.9
  • Weight：3000kg
  • Voltage：According to Customer Request
  • Power：27kw
  • Color：Orange
  • Transport Package：Nude Package,as Customers Request
  • Specification：CE, SGS
  • Trademark：ECENG
  • Origin：Zhangjiagang Jiangsu
  • HS Code：8477300000
  • Production Capacity：80 Sets Per Year

Description

ItemYCQ-2L-2EBottle type specificationCavity2Theory output2400-2700Max.volume2LBottle mouth maximum overall diameter80mmBottle biggest diameter100mmBottle maximum height330mmPower specificationsLight tube quantity32pcsLight tube power0.75KWMaximum heating power24KWAll electric machine installation27KWActual consumption8.1KWAir pressure specificationWork pressure7-9kg/cm2Low-pressure gas consumption1000L/minBlow bottle pressure25-35kg/cm2Higher -pressure gas consumption1500Ltr/minForzen water specificationWork pressure5-6 kg/cm2Temperature range10Consumption5000kcal/hrForzen water flow30L/minMachine specificationSize of the machine2.25x1.6x1.7Weight of the machine2.5tonFully-Automatic Bottle Blow Moulding Machine with 2 CavityFully-Automatic Bottle Blow Moulding Machine with 2 CavityFully-Automatic Bottle Blow Moulding Machine with 2 CavityFully-Automatic Bottle Blow Moulding Machine with 2 Cavity
