• Model NO.：SWMNH-3
• Total Power：126kw
• Weight：7700kg
• Rotational Speed：30-55 R,Min
• Outline Dimension：22900*2530*3100mm
• Transport Package：PE Film
• Specification：CE, ISO, SGS
• Trademark：SKY WIN
• Origin：Nanjing, Jiangsu, China
• Production Capacity：90-160 Kg,H

Basic Info.

Model NO. SWMNH-3 Total Power 126kw Weight 7700kg Rotational Speed 30-55 R/Min Outline Dimension 22900*2530*3100mm Transport Package PE Film Specification CE, ISO, SGS Trademark SKY WIN Origin Nanjing, Jiangsu, China Production Capacity 90-160 Kg/H

Product Description

Waste Milk Box(Paper Carton) Extrusion Line



I. Practical Application:Products for landscape, decking, railing, fencing, wall panel, pallet, partition board, pipes, etc.

II. Advantages of the machines
It was a big problem in the world to recycle waste milk box because it is made from 65% paper, 30% LDPE and 5% aluminum. Even if people have separated the paper, PE and Al, they must spend a lot of money and make much pollution. SWMNH production lines are specially for producing WPC products using waste as raw material directly. III. Technical parameters

Machine Type	Output (Kg/h)	Total Power (KW)	L/D	Rotational Speed (r/min)	Outline Dimension (mm)	Weight (Kg)
SWMNH-1	40-60	75	10-32	30-70	15400*1500*2500	4900
SWMNH-2	70-100	103	10-32	30-55	20300*2230*2900	6000
SWMNH-3	90-160	126	10-32	30-55	22900*2530*3100	7700

SKY WIN ECO sticks to the responsibility of "Developing eco-friendly machines,turning waste into treasure,improving earth ' s environment"

SKY WIN develops various kinds of machines on circular economy,tries to form a whole chain of waste plastics recycling system,from crushing,cleaning and pelletizing to extrusion or injection molding.
