Ftpe-800 PE Air Bubble Wrap Film Making Machine
Ruian Fangtai Machinery Co., Ltd.- Type：Film Extruder
- Plastic Processed：PE
- Product Type：Granulating Extruder
- Feeding Mode：One Feed
- Assembly Structure：Integral Type Extruder
- Screw：Single-Screw
Base Info
- Model NO.：FTPE-800
- Engagement System：Full Intermeshing
- Screw Channel Structure：Deep Screw
- Exhaust：Exhaust
- Automation：Automatic
- Computerized：Computerized
- Screw Diameter：60mm
- Main Motor Pow：15kw
- Film Width：1000mm
- Output：60kgs,H
- Total Power：50kw
- L/D：28:1
- Liner Speed：1000m,H
- Transport Package：Wooden Case,Wooden Block,in Nude
- Specification：1000mm
- Trademark：Fangtai
- Origin：Ruian China
- HS Code：8477800000
- Production Capacity：20set,Month
Description
Casting-aluminum heating deviceWidth of Bubble Roller 680 mm 880 mm 1080 mm 1280 mm 1280 mm 1580 mm 1680 mm Width of Products 600 mm 800 mm 1000 mm 1200 mm 1300 mm 1500 mm 1600 mm Thickness 0. 06--0.25 mm 0. 06-0. 25 mm 0. 06-0. 25 mm 0. 06-0. 25 mm 0. 06-0. 25 mm 0. 06-0.25 mm 0. 06-0.25 mm Main Motor 7.5 kw 11 kw 15 kw 15 kw 15 kw 18.5 kw 18.5 kw Tractiong Motor 0.75 kw*2 1.1 kw*2 1.1 kw*2 1.5 kw 1.5 kw 1.5 kw*2 1.5 kw*2 Total Power 30 kw 35 kw 30 kw 58 kw 58 kw 70 kw 70 kw Rewinder Turnover duplex turret rewinding type Max. Output 35 kg/h 45 kg/h 50 kg/h 70 kg/h 70 kg/h 90 kg/h 90 kg/h Linear Speed 1000 m/h 1000 m/h 1000 m/h 1000 m/h 1000 m/h 1000 m/h 1000 m/h
