3D Air Duct With Rwds Blow Molding Machine

Suzhou OTO Machinery Co., Ltd.
  • Warranty：One Year
  • Type：Extrusion Blow Molding Machine
  • Raw Material：Teee,TPV,PA6
  • Making Method of Parison：Extrusion-Blow Molding
  • Automation：Automatic
  • Computerized：Computerized

Base Info

  • Model NO.：TKC-70AR
  • Certification：CE, ISO9001:2008, UL
  • After-sales Service：One Year
  • Transport Package：Wooden Case
  • Specification：32CBM
  • Trademark：OTO
  • Origin：China
  • HS Code：847740
  • Production Capacity：100set,Year

Description

Screw Diameterφ70mmL/D30:1Output70kg/hMold Platen Dimension700*900mmMold Platen Opening Stroke550~1100mmPressure14MPaClamping Force100KNAccumulator Volume2LMax. Die Diameter40mmFrame Lifting Stroke300mmExtruder Heating power19kwDie Head Heating Power16kwExtrusion Motor Power37kwServo Oil Pump Motor Power11kwAxial Wall Thickness Motor Power11kwRadial Wall Thickness StrokeXY Direction6mmRadial Wall Thickness Motor Power4kw*2Total Rated Power82kwAverage Power Consumption31kwMachine Dimension(L*W*H)6300*3500*4400mmMachine Weight12Ton                                                       The data are subject to further improvement without prior notice
