• Model NO.：GZ630mm-1600mm
• Condition：New
• Pipe Diameter：630mm-1600mm
• Vacuum Calibration Tank：Vacuum Pump, Water Pump
• Vacuum Lenght：12m
• Vacuum Pump：Yuhuan
• Water Pump：Yuhuan
• Vacuum Tank Type：Double Chamber Vacuum Tank
• Tank Shape：Polygon
• Tank Material：Ss304
• Tank Wall Thickness：6mm
• Inlet Water Diameter：2inches
• Transport Package：Wood Case and Wood Base
• Specification：630mm-1600mm
• Trademark：DEEDO
• Origin：Jiangsu, China
• HS Code：84778000

The First vacuum sizing machine1 PCE 1Vacuum Sizing tankfull vacuum spray 2Length2000mm 3Pipe diametersΦ630-Φ1200mm 4Vacuum  pump1 PCE 5Vacuum pump power7.5kw 6Water pump1 PCE 7Water pump power11kw 9Hydraulic instucture2.2KW 10Hydraulic tank moving distance1000mm 12left-right moving distance±50mm 13Central height1600±50mm 14Tank Materialstainless steel 15Wall thickness6mm 16Tank cover materialcast-aluminum 17Cooling methodspray 18Cooling mediumcooling water 19spray pipes12 PCS 20Nozzles' quantityAbout 230 Pcs 22pipe-carrying methodSemi-circle carrying panel 23outlet seal plate specificationDepend on customers 24,All the Fasteners and structure components inside the tank
Stainless steel or nylon componnents 25Liquid level controlling methodfloating ball+electromagnetic valve 26water inlet diameter2" 27
water outlet diameter1.5" 28tank sppearancepolygon
The Second Vacuum Sizing Machine(Piece) 1
vacuum sizing tankDouble-cavity spray 2Length10000mm 3Pipe diametersΦ630-Φ1200mm 4
Vacuum pumps2(PCS) 5Vacuum Pump power7.5kw 6Water pumps3(PCS) 7water pump power11kw 8Water pump seal ringMechanical seal ring 9Fro-back moving methodHydraulic structure 10Fro-back moving distance±700mm 12Left-right moving distance ±50mm 13central height1600±50mm 14tank materialStainless steel 15wall thickness6mm 16Tank cover materialcast-aluminum 17cooling methodspray 18Cooling mediumcooling water 19apray pipes10Pieces 20NozzlesAbout 500 PCS 22pipe-carrying methodsemi-circle carrying panel 23outlet seal plate specificationDepend on customers 24,all the Fasteners and structure components inside the tankstainless steel or nylon componnents 25Liquid level controlling methodfloating ball+electromagnetic valve 26water inlet diameter2" 27water outlet diameter1.5" 28tank appearancePolygon
