• Model NO.：80-120kg,h
• Trademark：BEIER MACHINERY
• Origin：China
• HS Code：84778000
• Production Capacity：50sets,Year

Basic Info.

Model NO. 80-120kg/h Trademark BEIER MACHINERY Origin China HS Code 84778000 Production Capacity 50sets/Year

Product Description


Film, Woven bag, Non-woven fabrics agglomerator & Pelletizing line


SJ70 PE/PP film agglomeration Pelletizing line
(Cold-strand type, Capacity: 80-120kg/h)

1.    Application for all kinds of PE,PP film, woven bag, non-woven fabrics recycling;
2.    Automatic PLC controlling for the flow of feeding film into agglomerator;
3.    With individual temperature controlling on agglomerator, cooled by fan;
4.    With the characteristics of agglomerator structure, convenient operation, stable performance.

Technical Parameter

Agglomerator:

Total volume: 200L
Motor power:30kW AC
Quantity of rotary blades: 6pcs; Quantity of fixed blades: 7pcs
Cooling of chamber: cooling fan, 2.2kW

SJ160 Single screw extruder
Dia. of screw: 70mm; L/D: 34
Main motor power: 37KW AC
Heating power: 22.5KW
