• Model NO.：Fg-4
• Cooling Water：22L,Min
• Total Power：50kw
• Dimension：3200mm*1150mm*2200mm
• Export Markets：Global
• Air System：6.0m3,Min 3.0MPa Air Compressor
• Raw Material：Pet
• Making Method of Parison：Injection Blowing
• Automation：Automatic
• Computerized：Computerized
• Certification：CE, ISO9001:2008, QS, UL
• Transport Package：Woodbox with Film Wrapped
• Specification：3200mm*1150mm*2200mm
• Trademark：faygo
• Origin：China
• HS Code：84778000
• Production Capacity：15sets,Month

Main ParameterModelFG-4CapacityDepend on bottle design5500-7200PCS/HApplicable PreformHeight<330mmNeck20mm-25mmApplicable BottleNeck20-25mmVolumeMax.2LiterHeightMax.328mmDiameterMax.105mmElectric consumptionInstall power51kwHeating oven powder46kwHeating Oven operating power26kwAir consumptionPressure4m3/min 4.0MPa Capacity4m3/min 4.0MPa Mold ChillerPressure4-6BarTemperature6-13ºCFlow45L/minOven ChillerPressure4-6BarTemperature6-13ºCFlow26L/minMachine DimensionL*W*H3900*900*2500mmWeight3500kgCapacity: 5000-5500BPH(based on 1L)Max. Volume: 2 Litter
Total Size:
Blowing Main machine: 3.6*1.3*2.3m
Sorting machine:2*1.5*1.5m/Loader:3*1*1.5m
Main electrics Pneumatic part& CylinderValveGERMAN Electric partPLCJAPAN MitsubishiServo SystemJAPAN PanasonicFrequency inverterJAPAN MitsubishiOperating systemJAPAN MitsubishiTouch screenJAPAN MitsubishiBlowingValveJAPAN ParkerOne-way ValveGERMAN Throttle ValveGERMAN Reducing ValveGERMAN DURAYNote: All the electrical components adopts CE,UL,CCC approved international
 advanced high-tech product
4. Our Services

1> The machine will be tested and checked at our workshop before delivery.

2>After one year, we will supply accessories are provided only one the cost price.

3> Free Spare Parts : Digital instrument, Sealing, Stretching cylinder seal ring, Mould-adjustment wrench, Furnace temperature table, Furnace heating tube and other relative vulnerable part..

4>Free production technology and process configuration.

5> We can help you to design the product line, workshop and provide turn-key project.

6>Installation: Experts' team to buyer's country after confirmation that the goods arrived in site and civil works completed get ready for installation. Funds for trip need to be payed by client and extra salary $100/day during the engineer's journey.

7>Warranty: One year from the date of Installation or acceptance of the Plant whichever comes first
