High Speed HDPE LDPE PE Poly Plastic Pbat PLA Biodegradable Dual-Screw Co-Extrusion ...

RUIAN YUNBANG MACHINE CO., LTD.
  • Warranty：One Year
  • Type：PE Film Blowing Machine
  • Raw Material：PE
  • Maximum Folding Width of Film：1500mm
  • Screw Diameter：75mm
  • Automation：Automatic

Base Info

  • Model NO.：SJ-
  • Computerized：Computerized
  • Machine Weight：4T
  • Certification：CE, ISO9001:2008
  • Film Thickness 0.005-0.08mm：Max.Layflat Width 400mm
  • Output: 150-200kg Per Hour：Material: PE,HDPE,LDPE,LLDPE
  • Inverter: Delta or Yasakawa：Colour: White and Blue
  • Transport Package：N,a
  • Specification：CQC, ISO9001, CE, SGS
  • Trademark：YUNBANG
  • Origin：China
  • HS Code：84773000
  • Production Capacity：500PC,Year

Description

Basic Info.

Model NO. SJ- Computerized Computerized Machine Weight 4T Certification CE, ISO9001:2008 Film Thickness 0.005-0.08mm Max.Layflat Width 400mm Output: 150-200kg Per Hour Material: PE/HDPE/LDPE/LLDPE Inverter: Delta or Yasakawa Colour: White and Blue Transport Package N/a Specification CQC, ISO9001, CE, SGS Trademark YUNBANG Origin China HS Code 84773000 Production Capacity 500PC/Year

Product Description

Product Description

Taiwan Quality High Speed HDPE LDPE PE Poly Plastic PBAT PLA Biodegradable Dual-Screw Co-Extrusion 3-Layer Blown ABA Film Blowing and Making Extruder MachineUSE:
It is suitable for blowing the plastic laminated film of low density polyethylene(LDPE), high density polyethylene (HDPE) and linear low density polyethylene (HDPE) etc.
Which are widely used for packing liquid, printed base material, products for export and industrial products, etc.

Characteristics:
1. Double/Three-layer Co-extrusion Laminated film can prolong the length for preservation of liquid package.
2. The cylinder and the screw stem of the extruder are made of high quality alloy steel with optimum hardness and durable service after precision finishing and nitrogen treatment.
3. The auxiliary machine has a platform working table for making operation easy and is equipped with bubble stabilizing ring.
4. Double-rolling and double-cutting coiling unit adopts torque motor to keep proper tensions and make rolling tidy and roll-changing easy. Please contact the salesperson for the latest quotation and machine configurations.

We can design the machines according to your needs.
ModelSJ-45×2/FM800SJ-50×2/FM1000SJ-55×2/FM1200
Screw Diameter2×45mm2×50mm2×55mm
Screw RatioL/D30:1
Bimetallic		L/D30:1
Bimetallic		L/D30:1
Bimetallic
Screw Speed12-110r/min12-110r/min12-110r/min
Output of Single-desk Extrude Machine55kg/h70kg/h90kg/h
Power of Main Motor2×11Kw2×15Kw2×18.5Kw
Caliber of Film Head100-150mm120-200mm150-250mm
Rotational Mode of Machine HeadContinuous rotationContinuous rotationContinuous rotation
Single-sided Thickness of Film0.02-0.10mm0.02-0.10mm0.02-0.10mm
Max Folding Width of Film800mm1000mm1200mm
Weight of Machine3500kg4500kg5200kg
Overall Dimensions4200×2200×4600mm4600×2400×5000mm5200×2700×6000mm
