Fully Automatic Special Film Rewinding Machine
Jiaxing Patsons Electronics & Machinery Co., Ltd.- Material：PVC and PE Cling Film,Blown Film and Casting Film
- Transport Package：Packing in Standard Export Wooden Case.
- Specification：Machine Model
- Trademark：PPD
- Origin：China(Mainland)
Base Info
- Model NO.：PPD-SFR500
- HS Code：84778000
- Production Capacity：10units,Month
Description
Basic Info.
Model NO. PPD-SFR500 HS Code 84778000 Production Capacity 10units/MonthProduct Description
Fully Automatic Special Film Rewinding Machine is complied with Imported PLC+LCD+Inverter control for simple operation,it is less skilled operator requires.It suits for both blown film and casting film for both PVC and PE cling film,with special pressing roller to drive off the air inside of the rewinding roll,the rewinding roll becomes transparency at soonest.One operator can run 3 machines at the same time,it is labor cost greatly reduced.
| Main Specification: | |
| Maximum width of mother roll: | 500mm |
| Total width of mother reel: | 550mm |
| Maximum OD of mother roll: | 500mm |
| ID of mother roll: | 76mm |
| Rewinding roll total width: | 550mm |
| Max OD of rewinding roll: | 180mm |
| ID of rewinding roll: | 25/32/38/50/76mm |
| Speed: | Max 1550rpm/min |
| Total power: | 4kw |
| Volt: | 110/220/240/380/415/450v,1&3ph |
| Pneumatic required: | 0.2Mpa |
| Weigth: | 1200KG |
