PVC and ASA Plastic Corrugated Roof Tile Sheet Rolling Forming Machine/Making Machine
Jiangsu Acemien Machinery Co., Ltd.- Type：Sheet Extruder
- Plastic Processed：PVC
- Product Type：Extrusion Molding Machine
- Feeding Mode：Multiple Feed
- Assembly Structure：Integral Type Extruder
- Screw：Twin-Screw
Base Info
- Model NO.：ASM-C-02
- Engagement System：Full Intermeshing
- Screw Channel Structure：Deep Screw
- Exhaust：Exhaust
- Automation：Automatic
- Computerized：Computerized
- Transport Package：Wooden Case with Plastic Film
- Specification：25*3*3.5m
- Trademark：acemien
- Origin：China
- HS Code：84778000
- Production Capacity：>1000pieces,a Year
Description
Auxiliary equipment13 SRL-Z300/600 Mixer unit 1set 14 PC500 Crusher 1set 15 MF550 Pulverizer 1set 16 Ridge roof forming machine(Optional)
1. Flat sheet haul-off unit
2. Oven
3. Ridge tile forming unit
4. Ridge tile mold
Raw material
Work condition (provide by customer)
Energy consumption
About Jiangsu ACEMIEN Machinery:
Jiangsu ACEMIEN Machinery Co., Ltd is specialized on plastic extrusion and recycling machinery manufacturing.
We have been producing and selling for over 6 years. Our equipment is exported to Asia, Africa, etc,
We have top-ranking Research and Development technology system and rich experienced technician team.
Our vision is to offer you the best and the most appropriate plastic extrusion and recycling solution, to offer you the most reliable technically and commercial service support.
Turnkey project service:
1. we will provide all the machines for the complete production according to customer's requirements.
2. we will provide complete service for factory layout and other information to help customer to build the factory.
3. we can also provide the raw material to the customer if you need.
4. we will provide good service for machine installation and training, until the customers can run the machines and make stably production.
5. Except one year quality guarantee, we will provide after-sell service for all the life.
6. For long-term cooperation, we always provide good quality, good price and good service to customer. we are the professional and trustable supplier for turnkey projects. Let us do win-win business together.
1. Flat sheet haul-off unit
2. Oven
3. Ridge tile forming unit
4. Ridge tile mold
Raw material
| Raw material & formulation | PVC powder, CaCO3, CPE, PE-WAX, Stearic acid , Compound stabilizer ,ACR, paraffin ASA granule |
| Description final product & Output capacity | Two layer PVC+ASA Co-extrusion Corrugated tile(trapezoid); Width:1130mm,Thickness: 1.5~3mm; Output:300-400kg/h(Depending on CaCO3 proportion) For 2.5mm thickness, Capacity about 2300 Sqr/day |
Work condition (provide by customer)
| Warehouse/Workshop | Dimension (M*M*M): 25(Length)×5(width) ×3.5 (Height) Crane: Machine positioning |
| Temperature & Humidity | ≤40ºC, ≤95% |
| Power supply | 3-phase, 380 V, 50 Hz(or customized) |
| Wire/cables: | Wires/cables from power supply to control cabinet of this production line; |
| Cooling Water hose/pipe | Water supply to machines and pools |
| Lubrication oil: | Sinopec, Exxon mobile |
| Compressor | 7.5kw(0.6-0.8Mpa) |
Energy consumption
| Installation power | Total 270KW,Actual consumption about 70% Suggested 200KVA transformer Needing at least 150KVA transformer |
| Cooling Water | ≤20ºC, ≥0.3Mpa, ~5-6tons/hr |
| Compressed air | 0.3m3/min, >0.6Mpa |
| Manpower | 3 Persons/shift(24 hours need 2-3 shifts) |
