PS Tray Thermoforming Machine

Ruian Hoin Machinery Co., Ltd.
  • After-sales Service：Technical Support Online
  • Warranty：One Year
  • Column number：Four Column
  • Molding Method：Pressing
  • Automatic Grade：Automatic
  • Transport Package：Film Packaging

Base Info

  • Specification：4.5m*1.1m*1.6m
  • Trademark：HOIN
  • Origin：Ruian,Wenzhou,China
  • HS Code：8477409000
  • Production Capacity：10sets,Months

Description

Material

PS/PET/PVC (Hard Sheet)

Sheet Thickness

0.3-0.6mm

Sheet Width

450mm

Max Install Area Of Mould

450×300mm²

Max Forming Depth

45mm

Productivity

10-30 Strokes/min

Heating Rated Power

About 10kw/hour

Total Power

30Kw

Main Motor Power

3Kw

Power Supply

380V/50Hz(Three Phase Four Wire)

Voltage

0.6-0.8Mpa

Air Volume Required

2500~3500L/min

Water Volume Required

40~45L/min

Machine Weight

About 2200

Overall Dimension

3m×1m×1.8m

C.MACHINE DETAILSPS Tray Thermoforming Machine
