WPC Profile Conical Twin Screw Extruder
SKY WIN Technology Co., Ltd.- Product Type：WPC Profile
- Screw：Multi-Screw
- Automation：Automatic
- Certification：CE, ISO9001:2008
- Customized：Customized
- Output：70-160kg,H
Base Info
- Screw Diameter：50,100
- Materials Processed：PE+Wood+ Additives
Description
Basic Info.
Screw Diameter 50/100 Materials Processed PE+Wood+ AdditivesProduct Description
. Practical Application:To produce profiles, sheets, thick-plates, pipes with WPC (PE/PP+wood powder) pellets.
II. Technical parameters
| Equipment Type | Screw Diameter (MM) | Total Power (KW) | L/D Ratio | Output(KG/H) | Outline Dimension (MM) | Total Weight (KG) |
| SWMSX-1 | 45/90 | 39.8 | 36-40 | 30-60 | 12000x1300x2400 | 4500 |
| SWMSX-2 | 50/104 | 47 | 36-40 | 60-90 | 16500x1400x2700 | 6500 |
| SWMSX-3 | 65/132 | 86 | 36-40 | 70-160 | 17500x1520x2800 | 7400 |
| SWMSX-4 | 80/156 | 127.6 | 36-40 | 250-350 | 18800x1850x2900 | 9400 |
| SWMSX-5 | 92/188 | 179.6 | 36-40 | 300-500 | 19000x2200x3100 | 15000 |
