Plastic Granulator for PE PP BOPP HDPE PA CPP PS, PVC
SKY WIN Technology Co., Ltd.- Raw Material：PE, PP, BOPP, HDPE, PA, CPP, PS, PVC
- Screw：Single-Screw
- Inverter：Inverter
- Automation：Automatic
- Computerized：Non-Computerized
- Customized：Customized
Base Info
- Certification：CE, ISO9001:2008
- Condition：New
- Screw Diameter：150mm
- Output：300kg,H
Description
Basic Info.
Certification CE, ISO9001:2008 Condition New Screw Diameter 150mm Output 300kg/HProduct Description
SKY WIN Technology Co., Ltd. is a high-tech joint-stock enterprise which combines research, manufacture and sales of WPC (wood-plastic composites) extrusion machines in China.
In the past 10 years, many experts in SKY WIN have concentrated on WPC extrusion lines (granulators, extruders, upstream and downstream machines, etc.) and now the company has accumulated a lot of experience on WPC equipment, molds, technical formula, and products.
SKY WIN wood-plastic machines are sold to over 200 customers in China, and over 30 customers in foreign countries, such as Itly, Russia, Poland, Singapore, Thailand, Saudi Arabia, UAE, Honduras, etc..
TECHNICAL PARAMETERS
ITEM | LGHB90 | LGHB100 | LGHB200 | LGHB300 | LGHB400 | LGHB500 |
Belt Conveyer | 1.1kw | 1.1kw | 1.5kw | 1.5kw | 2.2kw | 2.2kw |
Cutting Machine | 37kw | 55kw | 55kw | 75kw | 75kw | 90kw |
Screw Dia (mm) | 90 mm | 100 mm | 120 mm | 150 mm | 150 mm | 160 mm |
Srcew L/D | 20:1 | 22:1 | 25:1 | 26:1 | 28:1 | 30:1 |
Water-ring Cutter | 1.1kw | 1.1kw | 1.1kw | 1.5kw | 1.5kw | 2.2kw |
Hydraulic Screen Changer | 2.2kw | 2.2kw | 2.2kw | 3kw | 4kw | 4kw |
Air Supply System | 3kw | 3kw | 3kw | 4kw | 4kw | 5.5kw |
Output | 100kg/h | 100-150kg/h | 150-250kg/h | 300kg/hr | 400kg/hr | 500kg/hr |
