New Design Popular Mini Film Blowing Machine
Zhejiang Zhuxin Machinery Co., Ltd.- Type：PE Film Blowing Machine
- Raw Material：PE
- Maximum Folding Width of Film：1000-1200mm
- Screw Diameter：45
- Automation：Automatic
- Computerized：Computerized
Base Info
- Model NO.：MINI
- Machine Weight：2t
- Certification：CE, ISO9001:2008
- Model：2012 Chinaplas Type
- Transport Package：Wrapping Film
- Specification：CE
- Trademark：Changyin
- Origin：China
- HS Code：84773090
- Production Capacity：1000sets,Year
Description
HDPE,LDPE/LLDPEMax.Film Width 500MM 600mm Max.Extrusion Output HDPE:35kg/hr
LDPE:40kg/hr Blown Film Thickness HDPE:0.008-0.0.08mm
LDPE:0.02-0.10mm Extrusion Unit Hard-face Gear Case 133 146 Screw Diameter Φ45mm from Zhoushan China Φ50mm from Zhoushan China Screw Material 38 CRMOALA
38 CRMOALA Barrel's Material Screw L/D 30:1 28:1 Main Motor Power 11kw 15kw Frequency inverter Chinese brand or Delta Extrusion Die Die Size Screen Changer Standard Manual Standard Manual Thermo Control (Zone) 2 2 Cooling Blower(kw) 1.1 1.5 Center Steady Stick 1 pcs Take-up Unit Traction Roller Width φ138×600mm φ138×700mm Embossing Roller Width 600mm 700mm Take up Motor(kw) 0.75 Take Up Speed 10-80m/min Winding Unit Rewinding Type Single Rewinder.Surface Friction Winder Roller Width 600mm 700mm Winding Motor 10N.M 10N.M Rewinding Speed 10-80m/min Voltage 380V,50HZ,3PHASE
We can make the machine as your request.
