PE PVC Single Wall Corrugated Pipe Production Line
Qingdao Weier Plastic Machinery Co., Ltd.- Product Type：PVC Pipe
- Screw No.：Double-screw
- Automation：Automatic
- Computerized：Computerized
- Certification：CE, ISO9001:2008
- Customized：Customized
Base Info
- Model NO.：sjsz-65,132
- Condition：New
- PVC Corrugated Pipe Production Linoutput：100-200kg,H
- Pipe Diameter：75-160mm
- Total Power：75kw
- Application：Pipe
- Dimentions：15*4*4m
- Weight：12t
- Delivery Time：50working Days
- Transport Package：According to Customers Needs
- Specification：CE ISO9001 2008
- Trademark：WEIER
- Origin：Qingdao, China
- HS Code：84772090
- Production Capacity：89 Sets Year
Description
(1.) PE PVC single wall Corrugated Pipe Production Line:
This PE PVE double wll corrugated pipe production line also can be called twin wall corrugated pipe production line.
PE PVC Double-wall corrugated pipe production line made by qingdao benice machinery company is on the basis of absorbing foreign advanced technology and manufacturing processes, well-designed developed, This double wall corrugated pipe not afraid of acid, corrosion resistance and good sealing, no water seepage, high ring stiffness, friction coefficient, anti-aging, anti-electric erosion, softness and good features Applications for wires, cables threading pipe, washing machine drains, vacuum cleaner tubes, ventilation tubes, etc
(2.)Double wall corrugated pipe extrusion machine other features:
This double wall corrugated pipe extrusion machine can also dopt to PLC control system it is more accurate more intellectualize control order makes the operation more simple.
The production line is the single screw extruder in high efficiency, has the independent water and air circular system and form the double wall corrugated pipe by cooling water and compress air.
Corrugated forming system with strong cooling ability operation more simple efficiency,
The mould surface is nitrided, has the adjust equipment to adjust the wall thickness, it suitable for different diameters pipes. This double wall corrugated pipe has the features of long using life,corrosion resistance,etc. So it is widely used in the sewage water field.
The company's products are exported to Middle East, Africa, South America, Southeast Asia, Russia and other countries. The company's aim is: Quality, Honesty and Customers come first.
| Type | Pipe Diameter (mm) | PVC Output (kg/h) | PE/PP Output (kg/h) | MAX Speed (m/min) | Total Power (KW) |
| WR-160 | 90-160 | 150-250 | 200-300 | 6.0 | 9.7 |
| WR-250 | 110-250 | 250-350 | 250-350 | 5.0 | 8.6 |
| WR-500 | 200-400 | 650-750 | 250-500 | 3.0 | 16.9 |
| WR-800 | 500-800 | --- | 1000-1100 | 3.0 | 16.9 |
| WR-1200 | 800-1200 | --- | 1000-1200 | 1.0 | 30.0 |
