Rotomolding Equipment Rotomolding Mold Large Amusement Products Boats and Other Products ...
Zhejiang Benfan Machinery Co., Ltd.- After-sales Service：Available
- Warranty：1 Year
- Delivery Time：60 Days
- After-Sales Service Provided：Field Installation, Commissioning and Training
- Color：Customized Made
- Productivity：High
Base Info
- Model NO.：BF-5000CS-2A
- Power(W)：52.9kw
- Dimension(L*W*H)：21*11*6.49m
- Weight：30ton
- Oven Thickness：150mm
- Max.Temperature of Oven：400 Degree
- Number of Arms：2 Arms
- Oven Diameter：5000*5000*5000mm
- Raw Material：HDPE, LDPE, LLDPE
- Max Load of Arm：3000kgs
- Control System：Siemens PLC
- Transport Package：Plywood Case, Rag-Rugs and PVC Film
- Trademark：BENFAN
- Origin：Zhejiang, China (Mainland)
- HS Code：8477401000
- Production Capacity：5 Sets,Month
Description
| Machinery type: | Shuttle rotomolding machine |
| Heating supply: | Natural gas,liquefied gas,diesel oil |
| Temperature control: | DTE Control±2ºC |
| Burner system: | Riello |
| Cooling mode: | Fan cooling |
| Control mode: | Touch screen+PLC(Siemens brand) |
| Electric brand: | Schneider,Omron |
| Delivery time: | About 60 days after receive the deposit |
| Overseas Installation period | It depends on machine size,usually takes 10-20days |
| Heating rate: | 3 miniutes from room temperature to 280 degree in oven |
Benfan rotomolding machine advantage:
1. It only takes 3mins. from room temperature increase to 250 to 280 degree in oven
2. Arm is made of special alloy material which is good load
3. Full gear transmission, high efficiency
4. Full automatic operation
5. Heavy duty oven and energy saving
6. Loading and unloading easy for mould
7. Special deep cavity heating technical, suitable for complicated product
8. Internet remote control (if the machine has problem in your factory, we can solve the problem through internet)
9. PLC and Motors are Siemens brand from German,Burner is RIELLO from Italy,Bearing is NSK from Japan, all electrial compenents are using Schneider brand.
10. Big computer screen, bob-weight system, special made motor, thermostability sealing arm head etc
11. Use circle oven, it is more uniform heat distribution on the mold, that means it is good for product making and also more energy saving.
