• Model NO.：YCQ-2L-4
• Bottle Volume：150ml-2L
• Output：3500bph
• Voltage：According to Customer Request
• Dimension(L*W*H) :4.5*1.6*1.9m：4.5*1.6*1.9m
• Color：Orange
• Cavity：4
• Power：43kw
• Weignt：3500kg
• Driven Type：Pneumatic
• Transport Package：Nude Package,as Customers Request
• Specification：CE, ISO
• Trademark：ECENG
• Origin：Zhangjiagang Jiangsu
• HS Code：8477300000
• Production Capacity：200 Sets Per Year

                           ItemYCQ-2L-4Bottle type specificationCavity4Theory output4000-5000Max. volume2LBottle mouth maximum overall diameter28-38mmBottle biggest diameter100mmBottle maximum height330mmPower specificationsLight tube quantity32pcsLight tube power1.25KWMaximum heating power40KWAll electric machine installation43KWActual consumption21.5KWAir pressure specificationWork pressure7-9kg/cLow-pressure gas consumption1600L/minBlow bottle pressure25-35kg/cHigher -pressure gas consumption3000Ltr/minFrozen water specificationWork pressure5-6 kg/cTemperature range10ºCConsumption8000kcal/hrFrozen water flow88L/minMachine specificationSize of the machine4.5x1.6x1.9Weight of the machine3.5ton

Transportation:
   It is located in the beautiful port city of Zhangjiagang with convenient traffic; it's about 150 km away from Shanghai.
Products:
   PVC/HDPE/PP-R pipe extrusion line, PVC & WPC profile extruding line and plastic sheet production lines with the relative auxiliary machine, PE film/ PET bottles recycling line and pelletizing lines.
Market:
   Our products have been exported to Middle East, Southeast Asia, South America and Europe etc. We received the universal confirmation and trust from our customers except of the precious experience.
Idea:
   Abide by the logos of "Sincerity, Development, innovation, Win-Win" constantly, we are honorable to cooperate with friends at home and abroad by providing the high quality products, technology and service!
