5 Gallon Semi Automatic Linear Pet Stretch Blow Molding Machine
Zhangjiagang Eceng Machinery Co., Ltd.- Raw Material：PET
- Making Method of Parison：Stretch Blow
- Automation：Semi-Automatic
- Computerized：Computerized
- Certification：CE, ISO9001:2008
- Product Max Volume：20L
Base Info
- Model NO.：YC-20L-1
- Capacity：100 Bottles Per Hour
- Material：Pet
- Cavities：1
- Machine Size：2.18*0.77*1.96
- Machine Weight：1000kg
- Color：Orange
- PLC：Mitsubishi
- Driven Type：Pneumatic
- Transport Package：Wooden Package
- Specification：CE ISO SGS
- Trademark：eceng
- Origin：Zhangjiagang Jiangsu
- HS Code：8477300000
- Production Capacity：30 Per Month
Description
Product SpecMax. product volume (L/cav) 20 Max. preform neck size (mm) 200 Max. product diameter (mm) 400 Max. product height (mm) 600 Cavities 1 Blow molding part Die force (KN) 150 Die stroke (mm) 340 Max. mould size (mm) 420*500 Mould thickness adjustable Mould spacing (mm) 400 Max. pulling stroke (mm) 500 Operation pressure (Mpa) 0.8-1.0 Operation air pressure consumption (1tr/min) 560 Blow pressure (Mpa) 1.2-2.8 Blow air pressure consumption (1tr/min) 650 capacity (pcs/h) 60-90 Machine size (LxWxH)(m) 2.18*0.77*1.96 Machine weight (KG) 1000 Oven Temperature grade (rate) 8 Heating time (S) 90-200 Voltage (V) 220 Frequency (HZ) 50/60 Total power (KW) 15-40 Oven Size (LxWxH) 2.37*0.68*1.65 Oven weight (KG) 380
Technology Advantage
l. Special design,high rigid compound die structure
2. Wide adaptability, suitable for every type mould thickness
3. Adjust convenience
4. No mould rolling out
5. More energy conservation,no need much air supply
6. High burnish principal axis, with very precise polishing, light action and low noise.
7. Short mould stroke,quick action
8. All ZG45 casting, with long timing process,very small transformation,can meet your precise request 100%
9. Hig dead-weigh, ensure the steady during the opeartion
Our Service
After-sales service
1.we will provide the bill of load on time to make sure you can get the machine quickly
2.when you finish the Preparation conditions ,our engineer will go to your factory to install the machine ,and give you the operating manual ,and train your employee until they can operate the machine well.
3.we provide one year warranty with spare parts free.
The sample service
1.we can send you the video of the running machine.
2.you are welcome to come to visit our company,and see the machine running in our factory,we can pick you up from the station near our city.
3.If we get the permission of the customer who has brought the machines from us ,we can tell you their contact imformation,you can go to vist their factory.
Customized service
1.we can design the machines according your requirements(materil ,power,filling type,the kinds of the bottles,and so on).
2.at the same time we will give you our professional suggestion,as you know,we have been in this industry for many years.
well-known for its fine quality for plastic bottle blowing machine
After sales service
1> Find our products through ecengmachinery.en.made-in-china.com Alibaba,GlobalMarket,Made in China,Globalsources,Tradekey.
2>After one year , we can help you to maintain the machine and the accessories are provided only one the cost price.
3>Every 3 year , we can help to overhaul the machine freely(labor).
4>Free production technology and process configuration.
5> We can help you to design the product line , workshop and provide turn-key project.
6>Installation: Experts' team to buyer's country after confirmation that the goods arrived in site and civil works completed get ready for installation. Funds for trip need to be payed by client and extra salary $60/day during the engineer's journey.
7>Warranty: One year from the date from the date of Installation or acceptance of the Plant whichever comes first.
Free Spare Parts : Digital instrument, Sealing, Stretching cylinder seal ring, Mould-adjustment wrench, Furnace temperature table, Furnace heating tube and other relative vulnerable part .
packing&shipping:
Transportation:
It is located in the beautiful port city of Zhangjiagang with convenient traffic; it's about 150 km away from Shanghai.
Products:
PVC/HDPE/PP-R pipe extrusion line, PVC & WPC profile extruding line and plastic sheet production lines with the relative auxiliary machine, PE film/ PET bottles recycling line and pelletizing lines.
Market:
Our products have been exported to Middle East, Southeast Asia, South America and Europe etc. We received the universal confirmation and trust from our customers except of the precious experience.
Idea:
Abide by the logos of "Sincerity, Development, innovation, Win-Win" constantly, we are honorable to cooperate with friends at home and abroad by providing the high quality products, technology and service!
welcome to you visit our factory!!!
