• Model NO.：ABLB90II
• Max Product Volume：18liters
• Station Number：Double Station
• Auto-Deflashing：with Auto-Deflashing
• Machine Weight：11ton
• Machine Size：4.2X3X3.2m
• Screw Diameter：90mm
• Screw L/D Ratio：25 L,D
• Max Mold Size：530X550mm
• Clamping Force：110kn
• After-Sales Service：Engineers Available to Service Machinery Overseas
• Max Mould Size：530X550mm
• Template Distance：240~660mm
• Max Die Mouth：180mm
• Screw：90mm
• Made in：China
• Transport Package：Film Packing
• Specification：40.32m³
• Trademark：Dawson
• Origin：Zhangjiagang, Jiangsu, China
• HS Code：8477301000
• Production Capacity：3360PCS,Day

Basic parametersSuitable materialPE.PP,PVC,PS,PETG,so onMax volume20LOutput capacity180~200 pcs/hSize4.6×3×2.4(M)Weight8.2TsystemSpecificationParametersNotePlasticizion systemSummarizeHigh efficient low power consumption plasticizion system, transducer control, self-protect function when started at low temperature ReducerHard finishing,High intension,Low noise reducer Screw∮90mm,L/D ratio 25, 38CrMoALACooling system availablePlasticization130Kg/HHDPEHeating Zone4 Aluminum HeaterAutomatic heatingHeating power8KW/H Extrusion MotorThree phase asynchronous motor (380V,50HZ) Cooling Fan4zone        Automatic coolingExtrusion systemSummarizeHigh-grade alloy steel, center feeding Die head number1 Center distance of die heads/ Max die mouth∮180mm Heating zone4   Stainless steel heating cycle Heating power5~7KW Clamping systemSummarize
 High intension, rigidity, center mold locking, stable mould opening and clamping system  Clamping force108KN Template distance240~660mm Max mould size530X550mm Mould materialHigh grade 50# steel Electric systemSummarizePLC+ touch screen(man-machine interface)standard extrusion blow molding machine controlling system(AUTO monitoring, fault-alarm, auto counting ,auxiliary function available)
Japanese Mitsubishi PLC
systemOperate interfaceTouch screen, automatic self-diagnose alarm system Temperature controlAutomatic temperature control module Movement controlJapanese Mitsubishi, Chinese/English
Version Electric protectionAmpere overload, electric short circuit self-protection function Hydraulic systemSummarizeMultiple function hydraulic integrated block Proportional control, high efficient Oil pump motorThree phase asynchronous motor 11kw (380V/220V,50/60HZ) Oil pumpImported double pump ValvesImported oil pump valves and connections Oil pipesDouble layer overpressure resistant System pressure60Kg/cm² Cooling systemSeparate water cooling cycle, oil cooler cooling system Pneumatic systemSummarizeTaiwan AIRTAC pneumatic system Air pressure0.6Mpa Air displacement0.9M3/min Electromagnetic valveTaiwan AIRTAC Cooling systemSummarizeSeparate cooling system of mould, barrel and oil system Cooling mediumWater Water flow90L/min Water pressure0.3-0.6MPa
