• Model NO.：HSD
• Customized：Customized
• Condition：New
• After-sales Service：All Life
• Diameter Range：315-1680mm
• Length：36m,40m,48m
• Main Extruder：Sj-90,33,Sj-120,33,Sj-150,33
• Installed Power：250kw,440kw,580kw
• Capacity：550-700kg,H,700-900kg,H,800-1200kg,H
• Transport Package：Standard Package
• Specification：EN253, EN448, EN728, ISO1133, ISO8501-1. ISO9001
• Trademark：HSD
• Origin：Qingdao China
• HS Code：8477209000
• Production Capacity：20 Sets

Basic Info.

Model NO. HSD Customized Customized Condition New After-sales Service All Life Diameter Range 315-1680mm Length 36m,40m,48m Main Extruder Sj-90/33,Sj-120/33,Sj-150/33 Installed Power 250kw,440kw,580kw Capacity 550-700kg/H,700-900kg/H,800-1200kg/H Transport Package Standard Package Specification EN253, EN448, EN728, ISO1133, ISO8501-1. ISO9001 Trademark HSD Origin Qingdao China HS Code 8477209000 Production Capacity 20 Sets

Product Description

Puf Pre-Insulated Pipe hdpe Casing Production Line for jacket extrusion


PE thermal insulation Pipe is also called Black Jacket Pipe or thin wall pipe.

The main equipment of the production line adopts Germany's most advanced screw technology, which is highly efficient and energy-saving.
The feeding section adopts a forced feeding system to make the output higher.
The head adopts KraussMaffei screw head technology, and the head weighs 12 tons. The operation is simple.
The vacuum sizing system makes the operator comfortable and comfortable;
 the rotating planetary automatic cutting system is perfect;
the pipe cutting is processed online once, without the need for secondary trimming, saving time and effort.
In a nutshell, the equipment has a simple production process, uses fewer people, and has high production efficiency.
The daily output can reach more than 20 tons. With high product yield and less waste, it can increase the benefits of the manufacturer. It can produce one-time processing and online production without secondary processing.
The production line adopts a PLC computer centralized control system, and the production is stable and reliable.
Compose of Processing Line
1. Automatic Vacuum Feeding
2. Drying Machine
3. Single screw Extruder
4. Mold
5. Calibrating
6. Vacuum calibrating water tank
7. Hauling Machine
8. Cutting Machine
9. Carrier
10. PLC Automatic Control System

Main Specifiction:

Style	PE-110/600	PE-365/760	PE-655/1380	PE-960/1680
Main extruder	SJ-75/33	SJ-90/33	SJ-120/33	SJ-150/33
Pipe diameter	Φ110-600mm	Φ 365-Φ 760 mm	Φ 655-Φ 1380 mm	Φ 960-Φ 1680mm
Capacity	250-300kg/h	400~500 kg/h	850~950 kg/h	900-1100kg/h
Installed power	160kw	420 kw	480 kw	580kw
Length	35m	36 m	40 m	48m

Our Workshop
