Waste Cooling Bag Film Recycling and Granulating Machine Manufacture
WENZHOU E-SHION MACHINERY CO., LTD.- Raw Material：PE
- Screw：Double-Screw
- Inverter：Inverter
- Customized：Customized
- Certification：CE, ISO9001:2008
- Condition：New
Base Info
- Motor：China,Siemens
- Gearbox：Shuguang
- Electric Parts：Chint,Schneider,Panasonic
- Screw Material：Alloy
- Auto Loader：Optional
- Temperature Control：China,Omron
- Manual Book：Included
- Maintain：Whole Life
- Tool Box：1set
- Spare Parts：Invluded
- Transport Package：Plastic Film
- Trademark：E-SHION
- Origin：China
- HS Code：8477201000
- Production Capacity：100sets,Month
Description
You maybe need film blowing machine. Please click here
Usage:
This plastic recycling machine is suitable for regeneration and granulation of waste plastics, as HDPE, LDPE, and PP, etc. It is equipped with fast screen changer unit and automatic temperature control. The granulating crusher uses adjustable speed motor, piloting with an extruding machine at the same discharging speed synchronistical. The unit is easy to operate, With a high output, steady performance, and favorable economic benefit.
Usage:
This plastic recycling machine is suitable for regeneration and granulation of waste plastics, as HDPE, LDPE, and PP, etc. It is equipped with fast screen changer unit and automatic temperature control. The granulating crusher uses adjustable speed motor, piloting with an extruding machine at the same discharging speed synchronistical. The unit is easy to operate, With a high output, steady performance, and favorable economic benefit.
Model
Gear box size
Main motor
Vice motor
Main screw length
Output
Machine
weight
Machine dimension
SJ-100-90
173-173
22kw
15kw
2000mm
80-100kg
1.5T
3600*950*2000mm
SJ-120-110
200-173
37kw
18.5kw
2400mm
120-150kg
1.6T
3800*950*2000mm
SJ-140-130
250-180
55kw
22kw
2800mm
180-250kg
1.8T
4000*950*2000mm
SJ-160-150
280-200
90kw
30kw
3200mm
250-350kg
2T
4200*1100*2200mm
SJ-180-160
315-200
110kw
37kw
3600mm
350-400kg
2.4T
4500*1100*2200mm
SJ-200-180
330-225
132kw
37kw
3800mm
400-500kg
2.8T
4800*1200*2400mm
