• Condition：New
• Transport Package：Standard Packing
• Specification：16-32mm
• Trademark：kebeln
• Origin：China
• HS Code：8477209000
• Production Capacity：1000PCS,Year

Basic Info.

Condition New Transport Package Standard Packing Specification 16-32mm Trademark kebeln Origin China HS Code 8477209000 Production Capacity 1000PCS/Year

Product Description

Extruder for double PVC pipe.
The production line is developed with the 1990s advanced technology of West Europe by our company. The main machine is SJZ51/105 or SJZ65/132 cone double-screw-stem extruder, is equipped with doubletube single-control stainless steel spraying shaper to form aproduction line. It avoids a waste condition when one tube is adjusted and the other one is affected. The auto single-control double drawing machine and cutting are combined with the fornt shaping technology to make operation more flexible. Let you enjoy economic benefit which is brought about by separately control double-tube extruding. The diameter of the extruded pipe is fromΦ20-Φ63. It can fully use the extruding capacity of the extruder. Even if it produces small diameter pipe, it can get great output, too.

screw diameter(mm)	65/132
quality of screw(pcs)	2
screw direction	opposite outward rotation
speed of screw rotation(r/min)	1-36
effective length of screw(mm)	1430
structure of screw	conical mesh
motor power(kw)	37
total power(kw)	100
max. capacity(kg/h)	250-300
quantity of barrel heating(pcs)	4
heating method	cast aleminum heating+ceramic heating
center height(mm)	1000
weight(kg)	.3200
dimension(L*W*H)(mm)	4500*1500*2400
