Rotary Die Water Cooling Extruder PP Material PP Film Blowing Machine Plastic Film Machine
Ruian Queensense Machine Co., Ltd.- Screw Diameter：75mm
- Certification：CE SGS
- Condition：New
- Warranty：1 Year
- Material：PP,PE
- Output：80kg,H
Base Info
- Model NO.：QS-F70
- Blow Moulding Type：Extrusion Blow Moulding
- Key Selling Points：High-Accuracy
- Year：2020
- Film Thickness (mm)：0.01 - 0.1
- Number of Layers：Single-Layer
- Voltage：380V
- Name：Film Blown Machine
- Plastic Processed：PP
- Screw Diameter (mm)：70
- Output (Kg/H)：40 - 60
- Automatic：Yes
- Transport Package：Film or Wooden
- Trademark：QUEENSENSE
- Origin：Zhejiang, China
- Production Capacity：20 Set,Sets Per Month
Description
Type
QS-F55
QS-F60
QS-F70
QS-F75
Diameter of screw
Φ55
Φ60
Φ70
Φ75
L/D
28:1
28:1
28:1
28:1
Folding width of film(mm)
100-500
100-600
300-800
400-1000
Single-face Thickness of film(mm)
0.01-0.1
0.01-0.1
0.01-0.1
0.01-0.1
Max. Extrusion(kg/h)
30
45
60
80
Power of main motor(kw)
15
18.5
22
30
Power of Traction motor(kw)
1.1
1.1
1.5
1.5
Length of Traction roller(mm)
550
650
850
900
Outline diameter(L×W×H)
4500×2000×3500
4800×2500×3800
5000×2800×4000
5500×3000×4800
Weight(T)
3KG
4KG
5KG
6KG
work shopTrade ShowsAdvantagesPackaging & ShippingRemoval MethodCompany Information
Service :
QUEENSENSE BORN OF GOOD SERVICE AND MACHINE. WE HAVE OUR MACHINE ENGINEER TEAM AND OVERSEAS SERVICE AVAILABLE.
WE ALSO HAVE PROFESSIONAL INSPECTION TEAM, GOOD SALES TEAM AND AFTER- SERVICE ONLINE 24 HOURS TEAM. OUR MACHINE IS QUALITY STRICKLY CONTROLLED.
WELCOME YOU TO JOIN US!
