• Model NO.：APB-250
• Transport Package：Plastic Film
• Specification：bale size: 980x800mm
• Trademark：QIANGYE
• Origin：Guangzhou China
• HS Code：8422400000
• Production Capacity：50 Sets,Year

Basic Info.

Model NO. APB-250 Transport Package Plastic Film Specification bale size: 980x800mm Trademark QIANGYE Origin Guangzhou China HS Code 8422400000 Production Capacity 50 Sets/Year

Product Description

Horizontal Automatic Two Ram Baler For Waste Plastic PET Bottle Waste Paper
Specialized in recycling and compressing the waste paper, plastic film, fabric etc, convenient for storage, saving labor cost.

Specifications

• Automatically compressing and baling, using USA ACCENT WIRE AUTOMATIC WIRE SYSTEM
• With two rams design, compact machine structure occupying small space.
• conveyor optional for feeding
• Photoelectric switch activates baler when charge box is full
• Unique double-cutting design of cutters improves the cutting efficiency and lengthens the lifespan of the cutters
• Particular anti-slide design of the machine makes nicer bales
• Unique trunnion-mounted frame and ball-end joint design for the main cylinder avoid the torque on the rod, which lengthens the lifespan of the seals
• Use differential technique for the hydraulic system, makes shorter cycle time so that improve the working efficiency and save electricity
• Automatic tension system ensures "brick-like" bales on all loose materials
• Adjustable bales length and bales quantity accumulating function make the operation of the machine more convenient
• Automatically detect and show the errors of the machine which improve the machine inspection efficiency
• International standard electric circuit layout, graphic operation instruction and detailed parts marks makes the operation been more easily understanding and improves the maintenance efficiency
• The press heads are specially processed by planomiller, ensures the precise running of the ram
• Use high quality hydraulic system from Taiwan, ensures the stable running of the machine
• The heavy duty machine body makes sure only flat ground is required by the installation

• Model		APB-250T
  Motor		37KW x 3
  Baler	Main cylinder (middle)	cylinder barrel:Φ325x250x3580mm piston:Φ180x3200mm
  	Main cylinder (two side)	cylinder barrel:Φ273x220x3580mm piston:Φ160x3200mm
  	Side cylinder	cylinder barrel:Φ135xΦ280x1630mm  piston:Φ200x1600mm
  	Bale size	W980*H800*L(adjust)
  	Feeding hopper	L2250*W1450
  	Control method	Automatic/manual
  	Oil tank	2595kgs
  Conveyor	Motor	11kw
  	Reducer	1:59
  	Width	1800
  Wire system	USA brand	Accent wire 470
  Cooling system	Water cooling	15Ton water tower
  Bale  weight	Plastic	600kgs/bale
  Capacity	Plastic	About6-8ton/hour
  Weight	Total wight	About 30Ton
  Voltage		380V50HZ/440V60HZ/220V60HZ
