Waste Plastic PE PP PVC Film Recycle Rubber Crusher Machine with Least Price

Jiangsu Acemien Machinery Co., Ltd.
  • Type：Hard Plastic Crusher
  • Raw Material：PVC
  • Structure：Tangential Feed
  • Knife Classification：Claw Knife Crusher
  • Knife Roll：Solid Knife Roller
  • Automation：Automatic

Base Info

  • Model NO.：ACE-009
  • Computerized：Computerized
  • Certification：CE, ISO9001:2008, SGS
  • Hydraulic：Quick Access to Cutting Chamber, Easy for Blades
  • Bearing：NSK, Japan
  • Material of Blade：Skdii
  • Transport Package：Wooden Pallets
  • Trademark：ACEMIEN
  • Origin：China
  • HS Code：84778000
  • Production Capacity：500 Sets,Year

Description


No.1 GE Crusher
 ModelGE500/500GE500/700GE500/1400Rotor diamter500mm500mm500mmRotor width500mm700mm1400mmFeeding opening500*500mm500*7000mm500*1400mmDrive motor22KW30KW55KWNo. of rotor knives6pcs, SKD-1110pcs, SKD-1110pcs, SKD-11No. of stator knives4pcs, SKD-114pcs, SKD-114pcs, SKD-11Hydraulic drive3.7KW5.5KW5.5KWScreen size10-14mm10-14mm10-14mmOutput capacity300-500kg/h500-700kg/h800-1000kg/h
No.2 GH Crusher
 ModelGH420/800GH630/1000GH700/1200GH700/1400Rotor diamter420mm630mm700mm700mmRotor width800mm1000mm1200mm1400mmFeeding opening420*800mm630*7000mm700*1200mm700*1400mmDrive motor45KW75KW90KW110KWMotor brandSiemensSiemensSiemensSiemensNo. of rotor knives6pcs, D210pcs, D214pcs, D214pcs, D2No. of stator knives4pcs, D24pcs, D24pcs, D24pcs, D2Hydraulic drive3.7KW5.5KW5.5KW5.5KWScreen size10-14mm10-14mm10-14mm10-14mmOutput capacity400-600kg/h800-1000kg/h1000-1200kg/h1200-1500kg/h
No.3 GF Crusher
 ModelGF800GF1000GF1200Rotor width800mm1000mm1200mmRPM500500500Drive motor37KW55KW75KWNo. of rotor knives6pcs, SKD-1110pcs, SKD-1110pcs, SKD-11No. of stator knives4pcs, SKD-114pcs, SKD-114pcs, SKD-11Screen size60mm60mm60mmOutput capacity200-300kg/h400-500kg/h700-800kg/h
No.4 SC Series Crusher
 ModelSC-20SC-30SC-50Rotor diamter350mm380mm500mmGrinder Chamber480*340mm660*400mm720*510mmDrive motor15KW22KW37KWNo. of rotor knives3*8pcs, SKD-113*11pcs, SKD-113*12pcs, SKD-11No. of stator knives2*2pcs, SKD-112*2pcs, SKD-112*2pcs, SKD-11Output capacity120-180KG/H240-300KG/H400-500KG/HMesh10-12mm10-12mm10-12mm
Note:
  • Cutting chamber and bearings are water proof version for wet processing of the granulating,
  • Heavy duty type rack, hydraulic drive for hopper opening. Easy for blades maintain,
  • Importing high quality blades from Europe.- Europe design, good performance for grinding,
  • Rotor- in heavy duty version with 3-5row cutters tapped into rotor.

Raw materials & Final products After crushing /shredding
Waste Plastic PE PP PVC Film Recycle Rubber Crusher Machine with Least Price
 After shipping,two engineers will go to customer's company to install and test machine,and teach customer's workers the operative skills.- pre-sales services:
we will take customers to visit our factory and check the machines quality from airport/bus station/train stations.

- we will re-designed the machines according to customer's different raw material formulations: driving motors power, electric power model, control method etc.- after sales services:
we will offer electric diagram, installation diagram, usage manual.

- we will offer the customers online introduction to solve the machines problems/send engineers for customers machines installation, running test, workers training, machines repairmen services etc.

- we will offer customers spare parts at cost prices all life long of the machines  .
Basic payment:Payment: T/T,L/C
Delivery: 25-60 days
Origin: China
Minimum Order: 1 set
Packing: wooden case with plastic film(also can according to customer's requirements)
Inspection: in house
Guarantee: 12months
