Product Description

WPC Steel Brushing Machine

I. Practical Application:
To treat with the surface of finished WPC products with steel brushing machine.

II. Technical parameters
SWDM300 Steel Brushing Machine for wood-plastic profile
1. Steel brushing roller diameter: 200mm
2. Steel brushing roller quantity: 2PCS
3. Motor power: 3KW
4. Rotational speed: 1420r/min
5. Belt width: 330mm
6. Speed control motor power: 0.75KW
7. Range of speed controlling: 0-900n/min
8. Profile feeding speed: 2-18m/min
9. Auto jacking system: Two units of guide screw
10. Motor for jacking: 0.75KW
11. Dust removal mouth: ∮ 100*2
12. Fan power for dust removal: 2.2KW
13. Useful processing width: 300mm
14. Useful processing thickness: 5-120mm
15. Weight: 1200Kg
16. Outline dimension: 2600*1800*1500mm
