HDPE Plastic Film Extruder with Printing Machine
RUIAN YUNBANG MACHINE CO., LTD.- Warranty：One Year
- Type：Dual Head Plastic Film Blowing Machine
- Raw Material：PE
- Maximum Folding Width of Film：1200mm
- Screw Diameter：65mm
- Automation：Automatic
Base Info
- Model NO.：HDPE Plastic Film Blowing Machine
- Computerized：Computerized
- Machine Weight：1.5t
- Certification：CE, ISO9001:2008
- Colour：Blue and White
- Certifiaction：CE, ISO9001, CQC, SGS
- Transport Package：N,a
- Specification：CQC, ISO9001, SGS, CE
- Trademark：YUNBANG
- Origin：China
- HS Code：84773000
- Production Capacity：12 Sets,Year
Description
Basic Info.
Model NO. HDPE Plastic Film Blowing Machine Computerized Computerized Machine Weight 1.5t Certification CE, ISO9001:2008 Colour Blue and White Certifiaction CE, ISO9001, CQC, SGS Transport Package N/a Specification CQC, ISO9001, SGS, CE Trademark YUNBANG Origin China HS Code 84773000 Production Capacity 12 Sets/YearProduct Description
This machine unit can film blowing and printing at the same time.Option Unit as below:
1. auto feeding
2.Air compressor
3.Special size die head
4. rotary die head
5. double widing
Technical parameters:
| Model | SJ50-YT2600 | SJ50-YT2800 | SJ65-YT2100 |
| screw Diameter (mm) | 50 | 50 | 65 |
| Screw L/D Ratio | 28:1 | 28:1 | 28:1 |
| Blowing film driving motor (kw) | 11 | 15 | 18.5 |
| Max. extrsion out put (kg/h) | 35 | 50 | 75 |
| Die size (mm) | Φ60,Φ100 | Φ80,Φ150 | Φ100,Φ200 |
| Width of Blowing Film (mm) | 600 | 800 | 1000 |
| Thickness of Blowing Film (mm) | 0.005-0.10 | 0.005-0.10 | 0.005-0.10 |
| Printing Length (mm) | 191-1200 | 191-1200 | 191-1200 |
| Max. Printing Width (mm) | 600 | 800 | 1000 |
| Total Power (kw) | 28 | 32 | 40 |
| Weight (T) | 3.5 | 4 | 5 |
| Overall Dimensions (L*W*H)mm | 6000χ2400χ4000 | 6200χ2600χ4300 | 6400χ2800χ4800 |
