- Model NO.：Multiple models
- Automation：Automatic
- Computerized：Computerized
- Certification：CE, ISO9001:2008, SGS,BV
- External Dimensions(mm)：5400X2400X3700mm
- Transport Package：Wooden Package,Film Package,Steel Frames Package,C
- Specification：CE SGS BV
- Trademark：SOYU
- Origin：China
- HS Code：84778000
- Production Capacity：1000sets,Year
Model | Motor power(kw) | Blade(mm) | Main blade rotation diameter(mm) | Main blade quantity(pcs) | Main axle rotating speed(rpm) | Cutting Chamber(mm) | External dimensions(mm) | Equipment weight(kg) |
| SYU1530 | 1.5KW | 18.5mm | φ200mm | 14 | 10-12rpm | 370x300mm | 850x560x1550mm | 500kg |
| SYU1940 | 7.5KW | 18.5mm | φ245mm | 20 | 16-25rpm | 480x400mm | 1860x900x1800mm | 1400kg |
| SYU1960 | 2x7.5KW | 30 | 480x600mm | 1950x900x1800mm | 1600kg |
| SYU1980 | 2x11KW | 42 | 480x800mm | 2180x900x1800mm | 1800kg |
| SYU2360 | 18.5KW | 25mm | φ290mm | 24 | 16-25rpm | 600x600mm | 2300x1000x1950mm | 3000kg |
| SYU2380 | 22KW | 32 | 600x800mm | 2500x1000x1950mm | 3500kg |
| SYU23100 | 22KW | 40 | 600x1000mm | 2700x1000x1950mm | 4000kg |
| SYU2680 | 18.5KW | 40mm | φ320mm | 20 | 16-25rpm | 660x800mm | 2410x1100x2050mm | 4200kg |
| SYU26100 | 22KW | 25 | 660x1000mm | 2810x1100x2050mm | 4600kg |
| SYU26120 | 22KW | 30 | 660x1200mm | 3010x1100x2050mm | 5000kg |
| SYU3380 | 2x22KW | 50mm | φ430mm | 16 | 10-15rpm | 830x800mm | 3000x1250x2150mm | 4700kg |
| SYU33100 | 2x30KW | 20 | 830x1000mm | 3200x1250x2150mm | 5200kg |
| SYU33120 | 2x30KW | 24 | 830x1200mm | 3400x1250x2150mm | 5700kg |
| SYU41100 | 2x30KW | 50mm | φ534mm | 20 | 10-15rpm | 1050x1000mm | 3660x1700x2650mm | 9000kg |
| SYU41140 | 2x37KW | 28 | 1050x1400mm | 4160x1700x2650mm | 10000kg |
| SYU41160 | 2x45KW | 32 | 1050x1600mm | 4360x1700x2650mm | 11000kg |
| SYU50130 | 2x55KW | 50mm | φ650mm | 32 | 10-15rpm | 1200x1300mm | 4200x2100x3000mm | 13000kg |
| SYU50180 | 2x55KW | 36 | 1200x1800mm | 5200x2100x3000mm | 14000kg |
| SYU61180 | 2x75KW | 75mm | φ800mm | 24 | 3-10rpm | 1500x1800mm | 5400x2400x3700mm | 20000kg |
| SYU61210 | 2x90KW | 100mm | 21 | 1500x2100mm | 6200x2400x3700mm | 23000kg |
| SYU80210 | 2x225KW | 150mm | φ980mm | 14 | 3-10rpm | 1900x2100mm | 7100x2900x4200mm | 26000kg |
| SYU80250 | 2x225KW | 17 | 1900x2500mm | 7600x2900x4200mm | 29000kg |
| SYU80300 | 2x225KW | 20 | 1900x3000mm | 8300x2900x4200mm | 32000kg |
Recycling Machinery Scrap Metal Shredder Manufacturing Plant Shredder
