PP Film Blowing Machine

HEBEI CHENGHENG PLASTIC MACHINERY TECHNOLOGY CO., LTD.
  • Type：High and Low Pressure Film Blowing Machine
  • Raw Material：PP
  • Maximum Folding Width of Film：600mm
  • Screw Diameter：60mm
  • Automation：Automatic
  • Computerized：Computerized

Base Info

  • Model NO.：CHSJ--40,45,50,60F
  • Machine Weight：2.2ton
  • Certification：CE, ISO9001:2008
  • Model：Chsj--40,45,50,60f
  • L/D Ratio of Screw：L,D 30:1
  • Main Motor Power：11kw
  • Maximum Capacity Kg/H：10-70kg,H
  • About The Machine Weight：2250kg
  • Payment Term：T,T
  • Packing Details：Wooden Cases
  • Transport Package：Wooden Cases
  • Specification：SGS
  • Trademark：CHENGHENG
  • Origin：China
  • HS Code：8477309000
  • Production Capacity：20-100PCS,Month

Description


ModelCHSJ--40FCHSJ--45FCHSJ--50FCHSJ--60FDiameter of screwΦ40 mmΦ45 mmΦ50 mmΦ60 mmL/D ratio of screwL/D 30:1Die Head SpecificationΦ80 mmΦ90 mmΦ160 mmΦ180 mmFilm thickness(mm)0.015-0.06 mmFilm width(folding diameter)30-250 mm35-400 mm50-500 mm50-600 mmTotal Power11 kw15 kw18 kw21 kwMaximum capacity kg/h10-25 kg/h10-35 kg/h10-48 kg/h10-70 kg/hWeight≈1.9 T≈2.0 T≈2.1 T≈2.2 TOverall dimension5×2×3.3 m5.2×2.1×3.4 m5.3×2.2×3.5 m5.4×2.3×3.6 m

Purpose
Making use of bottom blowing technology, this Film blowing Machine is used to blow PP, LDPE and LLDPE plastic film,mainly applying for strain bag packing film.

Service
1.Free installation and ajustment.(for consumers purchase more than $100000 only)
2.Five years free after-sales service and mechanical parts lifetime warranty.
3.We will offer you the professional answers about the relating machines in 24 hours
