PVC Corrugated Pipe Production Line
Qingdao Jinfuxin Plastic Machinery Co., Ltd.- Product Type：PVC Pipe
- Automation：Automatic
- Computerized：Non-Computerized
- Certification：CE, ISO9001:2008
- Max. Output：100kg,H
- Transport Package：Wooden Pallet or Nude
Base Info
- Model NO.：SJSZ-92,188
- Specification：SGS, ISO, CE, 16-800mm
- Trademark：Jinfuxin
- Origin：Qingdao, China
- HS Code：84778000
- Production Capacity：20sets,Year
Description
Basic Info.
Model NO. SJSZ-92/188 Specification SGS, ISO, CE, 16-800mm Trademark Jinfuxin Origin Qingdao, China HS Code 84778000 Production Capacity 20sets/YearProduct Description
Qingdao Jinfuxin Plastic MachineryPvc pipe extrusion line
Pvc pipe production line
Pipe extruder machine
Pipe extrusion machine.
Pvc Plastic Pipe Extruder Making Machine
CE&ISO quality certification
High quality pvc corrugated pipe production line
Pvc corrugated pipe production line consists of vibration screen, high-speed mixer and cooler, plastic powder charger, cone twin-screw plastic extruder, (single-screw extruder) head, double-wall bellow forming machine, plastic pipe-expanding machine, loading rack, water cooler, air compressor, etc., mainly applied for producing PVC and PE plastic double-wall bellows and single-wall bellows.
| Type | Pipe Diameter (mm) | PVC Output (kg/h) | PE/PP Output (kg/h) | MAX Speed (m/min) | Total Power (KW) |
| WR-160 | 90-160 | 150-250 | 200-300 | 6.0 | 9.7 |
| WR-250 | 110-250 | 250-350 | 250-350 | 5.0 | 8.6 |
| WR-500 | 200-400 | 650-750 | 250-500 | 3.0 | 16.9 |
| WR-800 | 500-800 | --- | 1000-1100 | 3.0 | 16.9 |
| WR-1200 | 800-1200 | --- | 1000-1200 | 1.0 | 30.0 |
