Product Description

According to characteristics of flattened and round waste material of PET bottles,SKY WIN designed special
processing system to crush and wash it, New technology of continuous discharging steamer is adopted instead of
traitional steamer,with PLC controlling system and high quality.
Production Process:
Belt Conveyer→Bale Opener→Belt Conveyer→Drum Separator→Belt Conveyer→Off Lable Machine→Belt
Conveyer→Steam Washing→Belt Conveyer→Sorting Platform→Water Crusher→Screw Feeder→High-speed
Friction Washing→Screw Feeder→Washing Separator→Screw Feeder→High-speed Friction Washing→Screw
Feeder→Continous Hot Washer→Screw Feeder→High-speed Friction Washing→Screw Feeder→Washing
Separator→Screw Feederr→Efficiency Dewatering Machine→Heating Box→Hot Air Pipe→Winnowing Machine
→Stock Bin
Technical Parameters


Model	Power(KW)	Capacity(KG/H)
PETQX500	208	500
PETQX1000	224.2	1000
PETQX1500	264	1500
PETQX2000	328	2000
