Pet Series Energy Saving High Speed Preform Injection Molding Machine
Zhangjiagang Proman Machine Co., Ltd.- Structure：Horizontal
- Plastic Type：Thermoplastic
- Plasticizing Way：Screw Type
- Clamping Way：Hydraulic & Mechanical
- Automation：Automatic
- Computerized：Computerized
Base Info
- Certification：CE, ISO9001:2008, GMP, QS, UL
- Model NO.：PMI
- Clamping Force：950~8000kn
- Motor：Energy Saving Pump
- Controlled：PLC (Siemens)
- Application：Pet Preform , Bottle Cap
- Voltage：Customed Avaiable
- Transport Package：Wooden Cases
- Specification：6.5m*2.1m*2.5m
- Trademark：Proman Machine
- Origin：China, Jiangsu
- HS Code：8477101090
- Production Capacity：150machines,Year Water Production Line8
Description
PM-950APM-1300A PM-1600A PM-2000A PM-2400A PM-3000A PM-3800A PM-4800A screw diameter 32 35 30 35 40 35 40 45 45 50 55 50 55 60 55 60 65 60 65 70 65 70 75 70 75 80 screw l/d ratio(l/d) 20 18.8 24.5 21 18.4 24 21 18.7 23.3 21 19.1 23.1 21 19 22.9 21 19.4 22.7 21 19.5 22.6 21 19.6 22.6 21 19.7 theoretical shot volume(mm³) 113 135 113 154 201 173 226 286 358 442 534 491 594 707 665 791 921 848 995 1154 1061 1231 1413 1346 1545 1758 shot weight(ps)(g) 101 121 103 140 183 158 206 260 326 402 486 447 540 643 605 720 845 772 905 1050 966 1120 1286 1225 1406 1600 injection pressure(mpa) 232 194 249 183 140 235 142 142 219 178 147 215 178 149 210 176 150 207 176 152 203 175 152 201 175 154 theoretical injection rate(ps)(g/s) 62 72 67.5 91.8 120 110 181 182 142 175 212 145 175 208 176.5 210 245 241 283 328 308 357 410 370 423 484 plasticising capacity(g/s) 11 12 8.3 12.5 18 13.8 19.7 27.1 20.1 26.5 34.2 22.5 28.7 35.4 26.4 32.5 40 35.2 43.3 51.8 50.6 60.5 71.5 60.4 71.4 83.7 max.screw rotate speed(t/min) 220 260 250 200 170 150 150 150 150 injection stroke(mm) 140 160 180 225 250 280 300 320 350 clamping unit max.clamping force(kn) 700 950 1300 1600 2000 2400 3000 3800 4800 max.opening stroke(mm) 290 340 400 460 500 530 590 680 770 space betweeen(mm) 320*320 360*360 420*420 480*480 505*505 555*555 610*610 680*680 760*760 mould height 120-300 135-380 160-440 180-500 190-530 200-570 220-630 250-710 280-790 max.daylight(mm)590 590 720 840 960 1030 1100 1220 1390 1560 other pump motor power(kw) 9 11 13 15 18.5 22 30 37 45 heating power 6.2 7.3 9.2 13.6 16.6 16 16 16 16 heating zone 4 4 4 4 4 18.5 22 25 28 net height 2.7 3.2 4.3 5.6 6.4 8 11 15 19.8 oil tank capacity(t) 230 260 360 420 420 440 560 820 850 international designation(l) 700-230 950-280 1300-410 1600-785 2000-1060 2400-1390 3000-1750 3800-2150 4800-2710
