• Model NO.：DSB80II
• Application：Bottles,Jars,Cans,Gallons,Jerry Cans
• Station：One Station or Two Station
• Die Head：Single Head or Double Head
• Auto-Deflashing：Available
• Mould：One Cavity or Two Cavity
• Made in：China
• Suitable：0-5L
• Material：HDPE,PP,PVC,LDPE
• Color：Available
• Max Volume：5L
• Electromagnetic Valve：Taiwan Airtac
• Cooling Medium：Water
• Water Flow：100L,Min
• Water Pressure：0.4-0.6MPa
• Air Pressure：0.6~0.8MPa
• Transport Package：Nude Package,as Customers Request
• Specification：DSB80II
• Trademark：DAWSON
• Origin：Zhangjiagang Jiangsu
• Production Capacity：as Per Samples

PE.PP,PVC,PS,PETG,so onMax volume4 LOutput capacityas per samplesSize4.4×3.4×3.6(M)Weight11.3T SummarizeHigh efficient low power consumption plasticizion system,transducer control,self-protect function when started at low temperature ReducerHard finishing Heating power10KW/H Cooling FanSeparate cooling system for heaters         Automatic cooling     Cooling systemSummarizeSeparate cooling system of mould, barrel and oil system Cooling mediumWater Water flow100L/min Water pressure0.4-0.6MPa

1.Hydraulic system and valves connections from Japanese Yuken industry.



2.Computer control system (PLC) Japanese Mitisubishi PLC     Used to control all electrial components and touch screen

3.Auto-deflashing Unit
Remove extra parts of    products automatically
Saving your labor cost



4.Electric CabinetAll electric components
From famous world brand to ensure the quality and stability
5.Touch screen
Chinese and English
(or other language)All movement operated
By touch screenMake the process full-automatic

Machine's color can be customized according to your needs.
