• Automation：Automatic
• Computerized：Computerized
• Customized：Customized
• Certification：CE, ISO9001:2008
• Condition：New
• Origin：China

Basic Info.

Automation Automatic Computerized Computerized Customized Customized Certification CE, ISO9001:2008 Condition New Origin China

Product Description

plastic Granulator crusher PVC PE PP granulator grainder machine
Granulator-rotor we have 10 rotor and 4 stationary knives or 6 rotor and 4 stationary knives. All knives use only high quality D2 (equivalent to SDK11) high-carbon, high-chromium steel which ensures longest usage times before requiring sharpening. All knives are easily adjustable with hydraulic assisted access to the cutting chamber. Depending on your application, we provides both dry and wet grinder.
Characteristics of Plastic granulator, crusher, grinder machine:
Plastic Granulator(Crusher/Grinder) based on advantages of the PC series was developed into an economical Granulator(Crusher/Grinder), although without insulation sound cabinet and it appearance is more perfect,
Our new design of the Grinder(Crusher/Granulator), it is easy for change the knifes (blades). The knife can change front or back.
Granulator(Crusher/Grinder)is widely applicable to grinding variety of solid waste products, such as injection parts, waste plastic films, sheet, bottles, electric wire, cables, woven bags etc. it can be granulating high quality and uniform granules.
Easy to operate, low electricity consumption & durable and low noise.
Uses high quality steel material especially for making cutter of the crushers.
Blades base is made of high quality steel, hard to be broken and damaged; Blades base structure is stable and durable
Easy to clean and maintain: The hopper, crusher room, blades and screen can be removed and mounted easily.
Less occupied area.
We can also according Client requirement to produce.
Suitable for recycling PVC PE HDPE LDPE PP and other plastics.
More introduction of the Plastic granulator, crusher, grinder machine:
The machine is fitted with a special hopper and can be loaded manually or by conveyor belt. This hopper can be adapted to suit individual requirements and ensures a continuous and efficient supply of the material being processed, without any need for manual assistance.
2. The Grinder is of extremely robust construction, and the rotor is driven by a belt drive configuration. On top of the Crusher is a feeding hopper which can be opened hydraulically. The hopper opening is also fitted with curtains to protect the materials from splashing out during operation.
3. The machine is equipped with a quick-change screen, which can opened extremely quickly via a hydraulic system; this helps to gain easy access to the rotor and cutting profile and grinding room, in order to save maintenance and operating cost.
4. The screen perforation is 14mm. This determines the final size of the finished products. The grinder is a fast running machine to reduce the materials to a defined granulates.

Technical Parameters of Plastic granulator, crusher, grinder machine:

Model	400	600	800	1000
Diameter of rotating blade (mm)	250	380	400	650
Quantity of rotating blade	12	18	24	24
Speed of rotating blade (mm)	560	560	560	560
Quantity of fixed blade	2	4	4	4
Diameter of screening sieve hole (mm)	Φ10-14	Φ10-14	Φ10-14	Φ10-14
Capacity (kg/h)	80-100	250-350	400-500	700-800
Power (kw)	7.5	18.5	37	55
Size of the feeding inlet (mm)	260×400	400×600	420×800	600×1000
Weight(kg)	650	1200	1500	2000
