• Machine Weight：2.5t
• Model NO.：SJ-A50-65
• Certification：CE
• Film Width：1200
• Film Thickness：0.008-0.10mm
• Rewinder Station：Single Station
• Screw：50-65
• Warranty：One Year
• Screw Number：55
• Size：200-800
• Speed：50kgs
• Service：Oversea Technical Supply
• Transport Package：Seaworthy
• Specification：CE
• Trademark：QUEENSENSE
• Origin：CHINA
• HS Code：8477309000
• Production Capacity：35-80kg,h

Basic Info.

Model NO. SJ-A50-65 Machine Weight 2.5t Certification CE Film Width 1200 Film Thickness 0.008-0.10mm Rewinder Station Single Station Screw 50-65 Warranty One Year Screw Number 55 Size 200-800 Speed 50kgs Service Oversea Technical Supply Transport Package Seaworthy Specification CE Trademark QUEENSENSE Origin CHINA HS Code 8477309000 Production Capacity 35-80kg/h

Product Description

Use:

Its extruder, cylinder and screw rods are made of quality alloy steel that have been nitrized and processed in a precision way. Hence it is sound in hardness, durable in corrosion resistance. The specially-designed screw is of sound quality in plasticizing, which helps increase the production capacity. It is applied to blowing the plastic films like low density polytene (LDPE), high density polytene(HDPE) and linear low density polytene (LLDPE). It is widely applied to producing the packing bags for foodstuff, clothing, rubbish bag and vest ones.

Optional Equipment:

1)Auto Load
2)Air Compressor
3)Special Die
4)Die Rotary Device
5)Bouble Sides Winder
6)Up And Down.


Model	A50	A55	A65	A65-1
Diameter of screw	φ 50	φ 55	φ 65	φ 65
Rcduced diameter of film(mm)	100-600	200-800	300-1000	400-1200
Single-face Thickness of film(mm)	0.01-0.10	0.01-0.10	0.01-0.10	0.01-0.10
Max. Extrusion(Kg/h)	35	50	65	80
L/D	28: 1	28: 1	28: 1	28: 1
Power of main moto(kw)	11	15	18.5	22
Power of Tracion main moto(kw)	0.75	1.1	1.5	1.5
Heating Power(kw)	15	18	23	27
Outline diameter(L x W x H) (mm)	4800 x 1900 x 4100	5500 x 2100 x 4700	6500 x 2300 x 4900	6500 x 2500 x 5600
Weight(T)	1.5T	2T	2.3T	2.6T
