• Model NO.：psb-dz200~600
• Machine Type：EPS Machinery
• Warranty：1year
• Transport Package：Standard Export Package
• Trademark：VST
• Origin：Zhejiang, China (Mainland)
• Production Capacity：20 Unit , Month

Basic Info.

Model NO. psb-dz200~600 Machine Type EPS Machinery Warranty 1year Transport Package Standard Export Package Trademark VST Origin Zhejiang, China (Mainland) Production Capacity 20 Unit / Month

Product Description

Main Features:
1,Strong Structure:
   Machine is made of high-strength square tubes and thick steel plates.
   Machine's all six panels are through heat treatment to release welding stress, so that panels cannot deform under high temperature.
   After heat treatment, all panels are processed by sand blasting treatment t remove rust, then first painting and final painting is done to keep machine anti-corrosion.
2,Steam System:
   Use three ball valves to control steam, saving 20% steam comparing to traditional one main valve system.
   Steaming is controlled by Timer and three Germen electrical gauge switches, with a safty valve to save from gauge malfuncton situation.
3,Control System:
   Machine with PLC and touch screen for easy operation.

TECHNICAL DATA
Item		PB2000V	PB3000V	PB4000V	PB6000V	PB8000V
Mould Cavity Size		2040*1240*1030(mm)	3060*1240*1030(mm)	4080*1240*1030(mm)	6100*1240*1030(mm)	8140*1240*1030(mm)
Block Size		2000*1200*1000(mm)	3000*1200*1000(mm)	4000*1200*1000(mm)	6000*1200*1000(mm)	8000*1200*1000(mm)
Steam	Entry Consumption Pressure	DN50 25-45kg/cycle 0.6-0.8MPa	DN50 45-65kg/cycle 0.6-0.8MPa	DN150 60-85kg/cycle 0.6-0.8MPa	DN150 95-120kg/cycle 0.6-0.8MPa	DN150 115-160kg/cycle 0.6-0.8MPa
Compressed Air	Entry Consumption Pressure	DN40 1.5-2m³ /cycle 0.6-0.8MPa	DN40 1.5-2.5m³ /cycle 0.6-0.8MPa	DN50    1.8-2.5m³ /cycle 0.6-0.8MPa	DN50 2-3m³ /cycle 0.6-0.8MPa	DN80 2.5-3m³ /cycle 0.6-0.8MPa
Vacuum Cooling Water	Entry Consumption Pressure	DN40 0.4m³ /cycle 0.2-0.4MPa	DN40 0.6m³ /cycle 0.2-0.4MPa	DN40 0.8m³ /cycle 0.2-0.4MPa	DN40 1m³ /cycle 0.2-0.4MPa	DN40 2m³ /cycle 0.2-0.4MPa
Drainage	Vacuum Drain Down Steam Vent Air cooling went	Φ 100mm Φ 100mm Φ 100mm	Φ 125mm Φ 125mm Φ 100mm	Φ 125mm Φ 150mm Φ 150mm	Φ 150mm Φ 150mm Φ 150mm	Φ 150mm Φ 150mm Φ 150mm
Throughout	15kg/m³	4min/cycle	6min/cycle	7min/cycle	8min/cycle	8min/cycle
Connected Load		19.75Kw	23.75Kw	24.5Kw	32.25Kw	40.25Kw
Overall Dimension	(L*W*H)	5700*4000*2800(mm)	7200*4500*3000(mm)	11000*4500*3000(mm)	12600*4500*3100(mm)	15700*4600*3500(mm)
