• Automatic：Yes
• Blow Moulding Type：Extrusion Blow Moulding
• Ammeter&Voltmeter：Made in Wenzhou
• Year：2019
• Weight：2500kg
• Dimension(L*W*H)：5200X2200X4100
• Application：Film
• Voltage：380V,3pH,50Hz
• Blowing Machine：HDPE, LDPE Roll Film
• Plastic Processed：PE
• Transport Package：Film Wrapping
• Trademark：Queensense
• Origin：Zhejiang, China
• Production Capacity：20 Set,Sets Per Month

Product Description

two layer ldpe hdpe extrude common-extruding
ldpe extruder machine blow moulding machine
extrusion die head pe film blowing machine

This machine is applied to manufacturing printing or uncolored T-shirt bags made of HDPE, LDPE roll film. It adopts double stepping (servo) motor fixed length, and the feeding, sealing, cutting, punching holes and transporting are completed only in one process. It is of high degree of automation and good economic results.

Main Technical Varia

OverviewDetailed Images

Blowing Set:

Get raw materials (HDPE LDPE LLDPE EVA and granules ) in and blow plasitc film in a tube

Machine Region: Ruian, Zhejiang, China

With: Hopper/ Gear Box/ Motor/ screws/Die head/Air ring/ air pipes/Air blowers/Cover




Extrusion Unit

Screw Diameter(mm):50*2 55*2  60*2 65*2

Screw L/D Ratio:28:1/30:1

Screw&Barrel Material:38 CRMOALA

Heating Ring Material:Stainless Steel




Cylinder Cooling

Cylinder Cooling:250wx2

Driving Motor:15kwx2 18.5kwx2

22kwx2 30kwx2



Electrical Cabinet

Film width: 200-800mm  300-1200mm

700-1500mm 1200-2000mm

Film thicness:0.02-0.20mm

Max. Extrusion Unit Output: 80kg/h 100 kg/h

135 kg/h 180kg/h



Double screw ABA die head

film blowing machine means

the machine is with two screw ,but can make three layer films.

A(PE)+B( Filling material)+A(PE), it save much cost of the film.



Winding Unit

Type of Winder:Single winder

Winding Station:Single Side one Station

Winding Roller:900mm 1300mm 1700mm 2200mm

Cylinder (Pic):1Pics

Winding Speed (M/min):5-50



Die Head

Model: QS-2G50 QS-2G55 QS-2G60 QS-2G65

Die Head Type:Die Head

Heating Ring Material:Stainless Steel

Die Head Diameter (mm):200 280 400 500



Driving Motor:15kwx2 18.5kwx2  22kwx2 30kwx2



Take-Up Unit

Take-up Unit:1 Units

Take-up Motor(kw):1.5

Take-up Speed(M/min):5-50
