Taiwan Quality High Speed HDPE LDPE PE Poly Plastic Pbat PLA Biodegradable Dual-Screw ...

RUIAN YUNBANG MACHINE CO., LTD.
  • Warranty：One Year
  • Type：PE Film Blowing Machine
  • Raw Material：PE
  • Maximum Folding Width of Film：1500mm
  • Screw Diameter：80mm
  • Automation：Automatic

Base Info

  • Model NO.：SJ-
  • Computerized：Computerized
  • Machine Weight：3t
  • Certification：CE, ISO9001:2008
  • Material：HDPE LDPE LLDPE EVA
  • Max.Layflat Width：1500mm
  • Film Thickness：0.005-0.08mm
  • Die Head：Rotary Die Head or Fixed Die Head
  • Transport Package：Film Package or Wooden Case
  • Specification：SGS
  • Trademark：YUNBANG
  • Origin：China
  • HS Code：84773090
  • Production Capacity：20 Sets,Month

Description

HDPE/LLDPE/LDPE/EVAScrew diameter(mm)4555657585Screw L/D Ratio L/D32:132:132:132:132:1Screw max. rotation speed150r/min150r/min150r/min150r/min150r/minExtruder driving power1518.5304575the way of screen changing of extruderHydraulic/pneumatic/manual twin-station changing screen quicklyAutomatic screen changerDie structureWith or without IBC(internal bubble cooling system)Air-ring structureRotary cual-lipReversing haul-off systemFilm turning modehorizontalAngle of reversing360Take-off wond-up speed60-80m/min60-80m/min60-80m/min60-80m/min60-80m/minTotal Power(kw)38506578100Weight(T)4.55710
 16
Taiwan Quality High Speed HDPE LDPE PE Poly Plastic Pbat PLA Biodegradable Dual-Screw Co-Extrusion 3-Layer Blown ABA Film Blowing and Making Extruder Machine
