Byb-150t Semi-Autoamtic Baler Press Baling for Waste Paper Plastic

GUANGZHOU PANYU QIANGYE MACHINERY CO., LTD.

After-sales Service：Video Support
Warranty：1 Year
Material Processed：Plastic Bottle
Plastic Type：PE
Screw：Single-Screw
Automation：Non Automation

Base Info

Model NO.：BYB-150
Computerized：Non-Computerized
Certification：CE
Name：Hydraulic Baler
Used for：Waste Paper, Plastic Bottle, Plastic Film
Transport Package：Wrap Film
Specification：1100x830mm
Trademark：QIANGYE
Origin：Guangdong, China (Mainland)
HS Code：8422400000
Production Capacity：20sets,Month

Description

Basic Info.

Model NO. BYB-150 Computerized Non-Computerized Certification CE Name Hydraulic Baler Used for Waste Paper, Plastic Bottle, Plastic Film Transport Package Wrap Film Specification 1100x830mm Trademark QIANGYE Origin Guangdong, China (Mainland) HS Code 8422400000 Production Capacity 20sets/Month

Product Description

BYB-150T Semi-autoamtic Baler Press Baling for Waste Paper Plastic
1.It is closed type hydraulic baler with lifting open-end door, no need to shift balers timely after package, it can push bags continuously.
2.It has high strength output door, hydraulic automatic open-end door, convenient operation and safety.
3.It configures with PLC program and electric button control, operated simply and equipped with automatic feeding detection, can compress bale automatically.
4.The baling length can be set at random, and provides bundling reminder device.
5.Artificial packing, pre-install strapping design, it only thread each wire or bundling rope around bale one time to complete skein, save labor.
6.Bale size and voltage can be customized according to customers' reasonable requirements. Bales weight depends on different materials.
7.Oil pipe joint uses cone links without gasket, has no phenomenon of oil leak.
8.Uses Taiwan imported superposition valve group.
9.The motor connects with pump directly to ensure 100% concentricity and prolong the service life of the pump.
10.Adopt unique concave type of multi-point cutter design to improve the cutting efficiency and prolong service life of the cutter.

Model

Baler size L*W*H(mm)

Work pressure

(KN)

Bale weight

(KG)

Main power

(KW)

Overall dimension

L*W*H(mm)

Total Weight

(KG)
