PVC Door Window Profile Production Line/UPVC Profile Making Machine/Plastic

Jiangsu Faygo Union Machinery Co., Ltd.
  • Type：Profile Extruder
  • Plastic Processed：PVC
  • Product Type：Profile Extrusion Molding Machine
  • Feeding Mode：One Feed
  • Assembly Structure：Separate Type Extruder
  • Screw：Single-Screw

Base Info

  • Model NO.：SJSZ65
  • Engagement System：Full Intermeshing
  • Screw Channel Structure：Deep Screw
  • Exhaust：Exhaust
  • Automation：Automatic
  • Computerized：Computerized
  • Material：PVC Powder
  • Finial Products：PVC Profile
  • Name：PVC Profile Production Line
  • Screw Material：38crmoaia
  • Heating：Omron Electric
  • Screw Cooling：Fan
  • Motor Brand：Siemens
  • Transport Package：Covered by PE Film
  • Specification：CE& ISO2001
  • Trademark：Jiangsu FAYGO Union Machinery Co., Ltd.
  • Origin：China
  • HS Code：847000
  • Production Capacity：200kg,H

Description


ModelMax.wide(mm)Extruder modelMax output(kg/h)Drive motor power(kw)FG108108SJZ51/10510018.5FG180180SJZ51/105 or SJZ55/110100/15018.5/22FG240240SJZ65/13225037FG300300SJZ65/13225037FG400400SJZ80/15635055FG500500SJZ80/15635055FG600600SJZ80/15640075
pvc profile production line Configuration:
1.Conical twin Screw Extruder ABB frequency converter, SIEMENS contactor, Japan, Motor power:75KW 2.Calibration unit calibration plate:1500mm×500mm 4couples 3. Cooling tank and bracket length:6000mm trimming knife:3 sets 4. Haul-off unit  5. Cutting unit 6. Stacker 7. Mould (T-Die )
Contact Supplier
Technology Details
pvc profile production line Packaging & Delivery

Packaging Details:		internal inspection,boot test,Moistureproof processing,composite material box,load container.
Delivery Detail:60 days after receiving downpayment

pvc profile production line for profiles With Price features:
1) Mainly used to produce the PVC window profiles, plastic decorative plates and PVC
foam profiles
2) Use frequency conversion for speed regulation
3) Has super-taper twin-screw extruder with temperature controlling instrument in the screw core
4) Saves power by 30% - 40%
5) The rigid gear surface of the reducer can be operated continuously for a long
time without trouble
6) Operation and mold changing are smooth and steadyPVC Door Window Profile Production Line/UPVC Profile Making Machine/Plastic
PVC Door Window Profile Production Line/UPVC Profile Making Machine/Plastic
7) Long usage life
8) Can produce steel plastic profiles by changing the wood imitation foaming profile
mold, combines with one set of steel liner conveying devices
