- Model NO.：JS2000
- Making Method of Parison：Stretch Blow
- Automation：Automatic
- Computerized：Computerized
- Certification：CE
- Transport Package：Wooden Box
- Specification：CE, SGS
- Trademark：JS
- Origin：Huangyan, Taizhou, Zhejiang, Pr. China
- HS Code：84773090
- Production Capacity：2000PCS,H
| | | JS-600B | JS-2000 | JS-2000B | JS-3000 | JS-4000 | JS-6000 | JS-600D | JS-600C | JS-1000 | JS-2000C | JS-2000X | JS-3000B |
| Production capacity | BPH | 600-900 | 1800-2200 | 1200-1600 | 2700-3000 | 3300-4000 | 5600-6000 | 300-500 | 450-650 | 1000-1200 | 1000-1200 | 2000-2300 | 1800-2400 |
| Number of Cavity | / | 1 | 2 | 2 | 3 | 4 | 6 | 1 | 1 | 1 | 2 | 2 | 3 |
| Clamping force | kN | 150 | 180 | 380 | 180 | 350 | 350 | 400 | 150 | 120 | 450 | 160 | 550 |
| Mould opening stroke | mm | 230 | 200 | 260 | 200 | 200 | 200 | 310 | 230 | 110 | 260 | | 260 |
| Stretch stroke | mm | 350 | 350 | 350 | 280 | 350 | 280 | 470 | 430 | 350 | 430 | 280 | 350 |
| Max. Container Volume | liters | 5 | 2 | 5 | 0.7 | 2 | 0.7 | 10-20 | 10 | 1.5 | 10 | 0.7 | 5 |
| Max. Neck Size | mm | 120 | 40 | 50 | 40 | 40 | 35 | 90 | 55 | 50 | 50 | 40 | 50 |
| Max. Bottle diameter | mm | 180 | 110 | 180 | 70 | 105 | 70 | 290 | 210 | 95 | 210 | 70 | 180 |
| Max. Bopttle height | mm | 350 | 350 | 350 | 280 | 350 | 270 | 480 | 430 | 350 | 430 | 280 | 350 |
| Installed Power | kW | 31 | 41 | 44 | 31 | 68 | 52 | 75 | 31 | 17 | 44 | 25 | 64 |
| Max. Heating Power | kW | 30 | 40 | 40 | 30 | 64 | 48 | 72 | 30 | 16 | 40 | 24 | 60 |
| Operating Air Pressure | Kg/cm² | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 |
| Operating Air Consumption | liters/min | 900 | 1500 | 2000 | 1500 | 3000 | 3000 | 1000 | 800 | 700 | 2000 | 1300 | 2000 |
| Blowing Air Pressure | KG/cm² | 30 | 35 | 30-35 | 35 | 35 | 35 | 35 | 30 | 30 | 30-35 | 30 | 30-35 |
| Blowing Air Consumption | liters/min | 2000 | 2000 | 4600 | 1800 | 3800 | 2800 | 6000 | 4000 | 1000 | 8000 | 1500 | 7000 |
| Cooling water Pressure | Kg/cm² | ,4-5 | ,4-5 | ,4-5 | ,4-5 | ,4-5 | ,4-5 | 4-5 | 4-5 | 4-5 | 4-5 | 4-5 | ,4-5 |
| Cooling water Temperature | °C | .10-20 | .10-20 | .10-20 | .10-20 | .10-20 | .10-20 | 10-20 | 10-20 | 10-20 | 10-20 | 10-20 | .10-20 |
| Cooling water Flow | liters/min | 100 | 100 | 100 | 100 | 100 | 100 | 100 | 100 | 100 | 100 | 100 | 100 |
| Measurement (L x W x H) | m | 2.5X1.5X2 | 2.6X2.2X2 | 2.6x2.25 x2.4 | 2.6X2.2X2 | 3.85X2.3X2 | 3.85X2.3X2.2 | 3.6X1.7X2.5 | 2.5X1.5X2 | | 2.6X2.25X2.4 | 2.5X1.9X2.2 | 3.2x2.25 x2.4 |
| Weight | Ton | 2 | 3 | 3.5 | 3 | 4.2 | 4.2 | 3.7 | 2 | 1.8 | 3.5 | 2.3 | 4.5 |
