• Model NO.：SJ-series
• Computerized：Computerized
• Machine Weight：4T
• Certification：CE, ISO9001:2008, UL, QS, GMP
• Transport Package：Simple Packing
• Specification：CE, ISO
• Trademark：YUNBANG
• Origin：Zhejiang, China
• HS Code：84773000
• Production Capacity：30 Set,Month

Basic Info.

Model NO. SJ-series Computerized Computerized Machine Weight 4T Certification CE, ISO9001:2008, UL, QS, GMP Transport Package Simple Packing Specification CE, ISO Trademark YUNBANG Origin Zhejiang, China HS Code 84773000 Production Capacity 30 Set/Month

Product Description

Film blowing machine, PE film blowing machine, pf film machine. Plastic film blowing machine, film
Machinery, plastic machinery, China film blowing machine

Use:
It applies to blow various LDPE, HDPE and LLDPE plasticfilms, widely applying to food, fruit, clothing, textile, vesttype bag and etc. Packingof civil industrial products.

Feature:
Mode SJ-50-85 squeezing machine is adopted rotatory die head, machine tube is adopted 38CrMoAl, having the best hardness and corrosion-resisting performance after nitrogen treatment and precision processing.

FM-600 auxiliary machine can adjust and operate freely within the range of 700mm in accordance with the technological demand of different materials, and having package board mechanism which can make vest type bag.

Rolling up device with double-drawing in and do-uble cutting ope, its power is adopted moment motor, with friction plate, it can keepsuitable tension, drawing in and rolling up in good order, easy to change roll.

Power of Main Motor	5.5-24KW
Assistance Machine	0.75KW
Heating	12KW
Die-Head	Φ 50-300mm Choose freely
Screw Diameter	Φ 45/50/55/65mm Choose freely
Screw L/D Ratio	L/D 28: 1
Screw Speed	10-100r/min
Max Ouput	30-70kg/h
Film Thickness	0.08-0.10 mm
Film Width	50-1200 mm
Weight	2-4.5T
