• Model NO.：SJ-
• Machine Weight：1.2 T
• Certification：CE, ISO9001:2008
• Screw Ratio：L,D28:1
• Power of Main Motor：7.5kw
• Max. Extrude Output：35kg ,H
• Single-Sided Thickness of Film：0.006 -0.10mm
• Transport Package：Film Package
• Specification：SGS
• Trademark：YUNBANG
• Origin：China
• HS Code：8477309000
• Production Capacity：20 Sets,Month

Basic Info.

Model NO. SJ- Machine Weight 1.2 T Certification CE, ISO9001:2008 Screw Ratio L/D28:1 Power of Main Motor 7.5kw Max. Extrude Output 35kg /H Single-Sided Thickness of Film 0.006 -0.10mm Transport Package Film Package Specification SGS Trademark YUNBANG Origin China HS Code 8477309000 Production Capacity 20 Sets/Month

Product Description

Product Description

Characteristics:
The cylinders and the screw stems of the above extruders are made of high-quality alloy steel with optimum hardness and strong corrosion resistance after revision finishing and nitrogen treatment. The auxiliary machine has a platform working table for making peration easy. The coiling unit adopts torque motor to keep proper tension and make rolling even and roll-changing easy.

USE:
It is used for blowing the various plastic film of low density polyethylene(LDPE), high density polyethylene (HDPE) and linear low density polyethylene(LLDPE) etc, Which are widely used for packing industrial products, textile, garments and food and for cohering farmland.

Model	SJ-45/600	SJ-55/800	SJ-60/1000
Screw Diameter	45mm	55mm	60mm
Screw Ratio	L/D28:1	L/D28:1	L/D28:1
Screw Speed	10-100r/min	10-100r/min	10-100r/min
Power of Main Motor	7.5KW	11KW	15KW
Max. Extrude Output	35kg /h	50kg /h	65kg /h
Max. Folding Width of Film	600mm	800mm	1000mm
Single-sided Thickness of Film	0.006 -0.10mm	0.006 -0.10mm	0.006 -0.10mm
Total Power	18Kw	22Kw	28Kw
Weight of Machine	2000kg	2200kg	2800kg
Overall Dimensions(L×W×H)	4200×1800× 3600mm	4400×2000× 4000mm	4600×2300× 4200mm

Model	SJ-65FM1200	SJ-80FM1500	SJ-100FM2000
Screw Diameter	65mm	80mm	100mm
Screw Ratio	L/D28:1	L/D28:1	L/D28:1
Screw Speed	10-100r/min	10-100r/min	10-100r/min
Power of Main Motor	18.5KW	30KW	55KW
Max. Extrude Output	76kg /h	86kg /h	160kg /h
Max. Folding Width of Film	1200mm	1500mm	2000mm
Single-sided Thickness of Film	0.006 -0.10mm	0.01 -0.10mm	0.02 -0.10mm
Total Power	32Kw	52Kw	80Kw
Weight of Machine	3300kg	4300kg	5800kg
Overall Dimensions(L×W×H)	4800×2500× 4500mm	5200×2800× 5000mm	6800×3300× 8000mm
