Disinfection Bottle Making Machine High Speed Inejction Blow Molding Machine

Zhangjiagang Dawson Machine Co., Ltd.
  • Type：Pet Injection Stretch Blow Molding Machine
  • Structure：Pet Injection Stretch Blow Molding Machine
  • Plastic Type：Pet
  • Plasticizing Way：Pet Injection Stretch Blow Molding
  • Clamping Way：Injection Stretch Blow Molding
  • Automation：Automatic

Base Info

  • Model NO.：ISB 1100N-3
  • Computerized：Computerized
  • Certification：CE, ISO9001:2008
  • Screw Diameter：50mm
  • Screw L/D Ratio：20.5:1 L,D
  • Screw Speed：0-190 R,Min
  • Theoretical Injection Capacity：238cm3
  • Injection Pressure：174MPa
  • Max.Hydraulic Pressure：140kg,Cm
  • The Actual Injection Quantity：225g(PS),8oz
  • Screw Stroke：190mm
  • Blow Clamping Force：150kn
  • Clamp Tonnage：600kn
  • Wheel Diameter：1100mm
  • Max. Height：220mm
  • Open Vertical Mode Trip：570mm
  • Max.Pump Pressure：16MPa
  • Servo Motor：22kw
  • Transport Package：Film Packing
  • Specification：ISB 1100N-3
  • Trademark：DAWSON
  • Origin：Jiangsu Zhangjiagang
  • HS Code：8477301000
  • Production Capacity：as Per Samples

Description

No.

Configurations Name

Brand Name

1

Oil Pump and Servo Motor(Double hydraulic system)

Eckerle (Germany) and Inovance

2

Hydraulic Valve

Yuken, TAIWAN

3

Sealing Parts

SealTech, China

4

F.R.L

China

5

Air Valve

AirTAC

6

Air Cylinder

AirTAC

7

Controller (PC)

JASU, Taiwan

8

Servo Motor for Turntable

Inovance,China

9

Gear Reducer

SESAME, Taiwan

10

Low-voltage components

Joint Venture
