Biodegradable Polyethylene PE HDPE Plastic Blown Extrusion Mini Making Film Small Extruder ...
RUIAN YUNBANG MACHINE CO., LTD.- Warranty：One Year
- Type：PE Film Blowing Machine
- Raw Material：PE
- Maximum Folding Width of Film：800mm
- Screw Diameter：55mm
- Automation：Automatic
Base Info
- Model NO.：SJ-
- Computerized：Computerized
- Machine Weight：2.5t
- Certification：CE, ISO9001:2008
- Gear Box：146
- Output：40kg,Hr
- Main Motor：15kw
- Die Head：Rotary Die
- Winder：Single Winder
- Transport Package：as Your Require
- Specification：CE. SGS
- Trademark：YunBang
- Origin：China
- HS Code：8477309000
- Production Capacity：15 Sets,Month
Description
Model
SJ45/50
SJ55
SJ60
SJ65
Suitable Material
HDPE
Max Film Width(mm)
600
800
1000
1200
Film Thickness(mm)
HD:0.008-0.08
Max Extrusion Output HD
30/40kg/hr
50kg/hr
60kg/hr
80kg/hr
Gear Box
133/146
173
173
200
Screw Diameter(mm)
φ45/50
φ55
φ60
φ65
Screw L/D Ratio
28:1
28:1
28:1
28:1
Screw's Material
38 CRMOALA
Barrel's Material
38 CRMOALA
Barrel's Cooling Fan
250W×2
370W×2
370×2
370×3
Thermo Control (zone)
3
3
3
4
Driving Motor (kw)
7.5/11
18.5
22
30
Die Size (mm)
HD:φ60/80
HD:φ80/100
HD:φ100/120
HD:φ120/φ150
Screen Changer
Standard manual
Thermo Control (zone)
2
2
2
2
Air Ring (mm)
φ620
φ620
φ620
φ760
Cooling Blower (kw)
1.5
2.2
2.2
3
Center Steady Stick
1 PCS
Roller Width (mm)
φ138×650
φ138×850
φ138×1100
φ138×1300
Embossing Roller Width
550mm
750mm
1000mm
1200mm
Take-UP Motor (kw)
0.75
1.1
1.1
1.5
Take-UP Speed(M/min)
10-60
10-60
10-60
10-60
Height adjustable type
700mm
Type OF Winder
Surface Friction Single Winder
Roller Width (mm)
700
900
1100
1300
Winding Motor (N.M)
6
10
10
16
Winding Speed(M/min)
10-60
10-60
10-60
10-60
Voltage
380V, 50HZ, 3PHASE
Cover Dimensions (m)
4.5×2.0×4.3
4.5×2.2×4.5
5×2.5×4.8
5.5×2.8×5.2
RUIAN Yunbang Machinery Co., ltd. has been the symbol of high quality and excellent service in machiery areas for many years, researched and developed our machines on basis of advanced technology introduced from developed countries. as a professional and experienced manufacturer in china, we're able to produce many kinds of machines like film blowing machine, bag making machine, paper bag machine, packing machine, printing machine and leather & shoe machines, ect.
