• Condition：New
• Output(Kg/H)：150-250kg,H
• Screw Rotary Speed：500rpm
• L/D：36-40

Basic Info.

Condition New Output(Kg/H) 150-250kg/H Screw Rotary Speed 500rpm L/D 36-40

Product Description

I. Practical Application:
To make WPC(PE+wood) pellets specially for extrusion, injection, etc.
II. Advantages of the machines
i. Designed according to characteristics of 65% wood filled into recycled or virgin PE, with stable function, goodeffect of mixing, plastication, etc.
ii. Able to expel moisture and gas easily because of several vents designed.
iii. Big output.
iv. Less attrition.
v. Building-block structure for screw, easy to change broken elements, and low maintain cost.
III.Technical Parameters


Equipment Type	Output (KG/H)	Total(KW)	L/D	Screw Rotary Speed(R/Min)	Outline Dimension (MM)	Total Weight (KG)
SWMSZ-1F	60-100	68	36-40	500	15000*2000*2800	4800
SWMSZ-2F	80-200	110	36-40	500	18000*2200*3200	5600
SWMSZ-3F	200-400	150	36-40	500	20000*2300*3800	7800
